Selective Wave Solder Equipment
| Quantity: | |
|---|---|
| Off-line Selective Wave Solder Equipment
The I.C.T off-line selective wave soldering machine is a high-performance system developed in China for flexible multi-wave needs in high-volume lines. PCB stays fixed while spray and soldering platform move for accurate results. N2 online heating wets solder perfectly and reduces dross. Full PC control sets paths, temperatures, flux, solder types, N2, with saved menus for traceability. Auto wave height calibration after each PCB ensures stability.
CCD mark positioning verifies every board. Lightweight cast aluminum table with Panasonic servos and linear rails moves fast, quietly. German jet valve sprays tiny flux dots, solid under 10%. Pressure tank keeps flux steady. German electromagnetic pump provides reliable peaks. Ti solder pot with cast iron heater avoids leaks, heats rapidly. This selective wave solder equipment excels as a selective PCB soldering machine.
| DIP Line Equipment List
German high-frequency pulse injection valve produces small, precise flux dots with solid content below 10%. Optional jam detection. Tray catches residue for easy clean. Nozzle on XY platform repeats to 0.02mm. Pressure tank stabilizes flow independent of level. Corrosion-resistant high-precision flow meter controls output. Japanese SMC pneumatics for reliability. Surface-mounted meters for visual checks. Humanized external design aids operation. SMC auto pump ensures constant supply. This flux module in the selective wave solder equipment applies uniform coating to through-hole points reliably.
Bottom IR preheating comes standard with adjustable positioning. Optional top IR heater or hot air convection. Structure engineered to enlarge effective heating zone. Full-surround high-temperature cotton insulation maintains consistent temperatures. Heat-generating components, conduction parts, and motors from leading brands ensure durable performance. Maintenance uses simple plug-in design for quick, tool-free access. This preheating stage in the selective wave solder equipment activates flux and reduces thermal stress on PCBs before contact with the wave.
German electromagnetic pump guarantees steady, reliable wave peaks. Software configures solder temp, N2, wave height, calibration. Ti pot prevents leakage, external cast iron heater for robust, quick heating. N2 inline heating perfects wetting, cuts dross. Best-in-class tin spray stability. Real-time CCD monitoring with 900-hour video traceability. Visual programming enhances speed. High-precision lightweight XYZ module with high-speed servos and reducers. Sealed anti-pollution. Omron sensors for exact motion. Auto nozzle cleaning with powder, flexible frequency. SICK laser detects wave height non-contact. Smart cleaning and measurement mechanism. This core delivers flawless joints in the selective PCB soldering machine.
Rational special material profiles ensure structural stability and easy maintenance access. Transmission consists of three roller parts for smooth board flow. PCBA secured by side clamps and top clamp system throughout process. Thickened customized rail bears up to 20KG loads. Handles PCB sizes up to 400x500mm, thickness 0.5-6.0mm, with 120mm top and 60mm bottom clearance. Front-to-rear direction, high-precision module for positioning. Integrates flux, preheat, soldering seamlessly. This transmission in the off-line selective wave soldering machine supports efficient, reliable PCB handling.
High-end PLC with module bus control ensures stable, scalable operation. Meets CE standards and Industry 4.0 with underfloor design. Integrates underlying soldering module control for increased throughput while keeping reliability. Applies worldwide high-quality stable electrical components. Cat-6 network cable provides quicker data transfer and responsive actions. Guided programming eases setup. CCD fast programming auto-detects nozzle types. Picture programming intelligently corrects and verifies coordinates. Real-time data visualization, one-button CCD monitoring switch. Multi-language: Chinese, English, Japanese, Russian. This control system in the selective PCB soldering machine enables complete parameter traceability.
Operating system features guided programming for step-by-step ease. CCD fast programming function with automatic nozzle type identification. Picture-based programming allows coordinate correction and intelligent verification. Interface displays real-time data visualization clearly. Switch to CCD soldering real-time monitoring with one button. Language switching: Chinese, English, Japanese, Russian, others. Intelligence includes MES standards, WIFI connection, online software upgrade, remote control. Human voice alarm and customization alarm light. Soldering data traceable to confirm each point's process. This user-friendly interface in the selective wave solder equipment suits operators of all levels.
| Specification
Off-line Selective Wave Soldering Machine | |
Model | I.C.T SS430 |
Flux Storage Tank | 1L |
Flux Support | Flux Alarm, Automatic |
Spray Nozzle | Germany Jet Valve (Spot and line spraying) 1set |
Spray Nozzle Size | 130um (180, 210um Option) |
Spray Range | 3~8mm |
Spray speed | 0~20mm/s |
Spray Nozzle move speed | 0~400mm/s |
Spray Precision | 0.1mm |
Spray Pressure | 0.05~0.1 MPa |
Preheating Mode | IR Heating |
Preheating Area | L500mm*W500mm |
Soldering Precision | ±0.25 mm |
Soldering monitoring | CCD |
Solder Capacity | 12Kg |
Max PCB Size | 500*500mm |
Max PCB Size | 60mm |
PCB Thickness | 0.5-6.0mm |
PCB Weight | <20Kg |
Operating System | Windows10 |
Power Supply | 220VAC±10%, 50/60HZ |
Dimension | L1400*W2580*H1722mm |
Weight | Approx:700kg |
