Application of PCBA Coating Line with Bottom Return Function in NEV Three-Electric Systems

Views: 0     Author: Site Editor     Publish Time: 2024-06-07      Origin: Site

Inquire

facebook sharing button
twitter sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


NEV Three-Electric Systems

New Energy Vehicle Electronics PCBA

NEV Three-electric System:


-- Motor System

-- Battery System

-- Electric Control System




The rapid development of new energy vehicles (NEVs) has made the three-electric system (motor system, battery system and electric control system) a key area of technological innovation. In this context, the application of coated wires with bottom feedback function offers a new solution to enhance the performance and reliability of NEVs. This article will explore the application of this technology in the three-electric system of new energy vehicles in detail.


Case Study:  PCBA Coating Line with Bottom Return Function in NEV Three-Electric Systems


Overview:

April 2024, Mexico, North America, fully PCBA coating line delivery completed sucessfully.


Taiwan-funded company with factories around the world, mainly OEM production of a variety of electronic products motherboards. The factory in Mexico, the equipment provided is fully automatic bottom return cycle coating line, the customer is mainly used to produce BYD series energy car three electric products, involving PCBA three anti coating, heat dissipation silicone and sealing silicone application.


Solution:

The maximum PCBA size is 710MM*500MM; PCBA coating machines, coating AOI inspection machine and other PCB handling machine are customized according to the product requirements.


1. Coating Process Flow:


  • PCBA Coating Lift → PCBA Coating Conveyor transfer → Coating by PCBA coating machine → Coating inspection at inspection conveyor → Curing in IR oven → Coating inspection at inspection conveyor → Coating AOI inspection coating effect → Transfer with reject conveyor → Flipping by flipper machine → PCBA Coating Lift code scanning and judgment →  Store PCBA with unloader machine


PCBA Coating Line with Bottom Return Function in NEV Three-Electric Systems

PCBA Coating Line with Bottom Return Function

PCBA Coating Line with Bottom Return Function in NEV Three-Electric System

PCBA Coating Line with Bottom Return Function


Learn more, please see the video :



  • PCBA Coating machine options:

    Long board mode 710MM*500MM, UPS, glue flow monitoring, automatic glue stirring function, automatic shutdown alarm reminder function for lack of glue, automatic program call function by QR code scanning, plate clamping system, bottom return function.


  • Coating AOI options:

    Long board mode, 710MM*500MM divided into two sections for detection, automatic program call function by QR code scanning, bottom return function.


2. Staffing of PCBA Coating Line:


According to the production line configuration and product adjustment, 1 operator and 1 engineer are expected.


3. PCBA Coating Line Solution Data:


PCBA Coating Line Configuration
Capacity Evaluation NEV Three-electric System Calculated based on PCBA size and coating process requirements
Power Max Power
Approximately 36KW
Operating power Approximately 18KW
Other Calculated based on actual equipment
Applicable products Mid- and high-end products can meet the requirements, maximum PCB width: 500MM
Line size L19.5m*W4m, total area 78 square meters


4. PCBA Coating Process Requirements:


1. Thickness control: The thickness of the paint film should be controlled within a certain range, between 50um and 150um, and the dry film thickness should be between 25um and 40um. In addition, the thickness of the primer, intermediate paint and topcoat also has corresponding requirements to ensure the reasonable distribution of thickness between each layer.


2. Coating uniformity: The three-proof paint layer should be flat, bright, and uniform in thickness, and protect the surface of the pad, patch components or conductors. Avoid paint flow, dripping, and defects such as bubbles, pinholes, ripples, shrinkage holes, and dust.


3. Coating quality: The paint surface and components should not have defects and foreign objects such as bubbles, pinholes, ripples, shrinkage holes, and dust, and there should be no powdering or peeling. During the coating process, avoid touching the undried paint film at will.

Secondary coating: To ensure the thickness of products with high protection requirements, secondary coating can be performed after the paint film is cured, but it is necessary to determine whether to perform it according to actual needs.


The application of PCBA coating lines with bottom return function in NEV three-electric systems offers significant improvements in performance, safety, and efficiency. As technology continues to advance, the potential for these solutions to enhance NEV systems becomes even greater. For customized solutions and further inquiries, please contact us.
