I.C.T-SS430
I.C.T
Selective PCB Soldering Machine
| Quantity: | |
|---|---|
| Off-line Selective Soldering Machine
The I.C.T off-line selective PCB soldering machine is a high-performance system developed and assembled in China for flexible multi-wave soldering in high-volume processes. PCB plate fixed while spray and soldering platform move for better accuracy. N2 online heating system wets solder perfectly and reduces solder dross. Full PC control sets parameters like moving path, solder temperature, flux type, solder type, N2 temperature, etc., with easy save and repeat for PCB soldering quality.
Auto wave height calibration function checks after every certain PCB to keep stable wave height. CCD mark positioning table with cast aluminum, lighter weight with quick motion speed. Panasonic servo motor and linear guide rail ensure less noise, stable movement. German jet valve creates small flux dots, flux solid content less than 10%. Electromagnetic pump coil adopts German imported brand for stability and reliability of the peak. Solder pot made of Ti, no leakage, with cast iron heater outside for robust, quick heat up. This selective PCB soldering machine optimizes the off-line selective wave soldering machine process.
| DIP Line Equipment List
High-frequency pulse injection valve gets precise fluxing result with small flux dot, flux solid content less than 10%. Flux nozzle jam detection function is optional. Tray under the jet valve catches flux residue for easy maintenance. Nozzle mounted on XY platform, accuracy of repetition and positioning can reach 0.02mm. Flux stocked by pressure tank, makes sure pressure stable without influence of amount of flux. High precision pressure flow meter used for flow control, corrosion resistant material.
All pneumatic components made of Japanese SMC brand. Flux pressure flow meter and nitrogen flow placed on surface of machine for visual operation. External humanized design is convenient for operation and adjustment. SMC brand automatic extraction pump adopted to ensure stable flux supply. This system in the selective PCB soldering machine ensures uniform, reliable flux application in the pcb selective soldering machine workflow.
Bottom preheating standard equipped in machine, position adjustable. IR heater of top, hot air optional. Design structure for maximizing preheating area. All round high temperature cotton design to ensure temperature stability. Heat-generating and heat-conducting parts and motors adopt top brands. Maintenance plug-in design, tool-free maintenance mode. This preheats PCBs evenly, activating flux and reducing thermal shock before the off-line selective wave soldering machine process.
Electromagnetic pump ensures stability and reliability of the peak. Solder temperature, N2 temperature, wave height, wave calibration all able to set in software. Solder pot made of Ti, no leakage, with cast iron heater outside, robust and quick heat up. N2 online heating system wets the soldering perfectly and reduces the solder dross. Best tin spraying stability in the industry. Real time visual monitoring and video can be saved and traced for 900 hours. Visual fast programming to improve programming reliability and efficiency.
XYZ platform composed of high precision lightweight sports module and high-speed servo motor. All servo motor equipped with reducer to ensure stability. Sealed and protected, anti pollution treatment. Omron Magnetic sensor ensures more accurate movement. Standard with nozzle automatic cleaning function, strong cleaning of nozzles with cleaning powder, cleaning frequency can be adjusted flexibly. German SICK laser detecting system for soldering wave height. Rational Design of Nozzle Cleaning and Measuring Mechanism. This core of the selective PCB soldering machine produces consistent, high-quality joints.
Special profiles provide stability and easy access. Three-part roller module transports boards smoothly. Side and top clamps hold PCBA firm during flux, preheat, and soldering. Thick rail supports up to 20KG load. Handles various PCB sizes with 120mm top, 60mm bottom clearance, 0.5-6.0mm thickness. High-precision module drives precise positioning from front to rear. Integrates seamlessly for efficient off-line selective wave soldering machine process.
High-end PLC plus module bus control offers reliable, scalable performance. Conforms to CE, Industry 4.0 underfloor layout. Enhances throughput via integrated soldering module control. Uses top worldwide electrical components. Cat-6 cables speed data and reactions. Guided programming simplifies use. CCD fast programming auto-identifies nozzle types. Picture programming corrects coordinates intelligently with verification. Real-time visualization, one-button CCD switch. Multi-language support: Chinese, English, Japanese, Russian. Traces every parameter in the pcb selective soldering machine for quality control.
Guided programming for easy steps. CCD fast programming with auto nozzle identification. Picture programming for smart coordinate correction and verification. Real-time data on clear interface. One-button switch to CCD monitoring. Languages include Chinese, English, Japanese, Russian. MES standards, WIFI, online upgrades, remote control. Voice alarms, custom lights. Soldering data traces each point. This interface in the off-line selective wave soldering machine process makes operation simple.
| Specification
Off-line Selective Wave Soldering Machine | |
Model | I.C.T SS430 |
Flux Storage Tank | 1L |
Flux Support | Flux Alarm, Automatic |
Spray Nozzle | Germany Jet Valve (Spot and line spraying) 1set |
Spray Nozzle Size | 130um (180, 210um Option) |
Spray Range | 3~8mm |
Spray speed | 0~20mm/s |
Spray Nozzle move speed | 0~400mm/s |
Spray Precision | 0.1mm |
Spray Pressure | 0.05~0.1 MPa |
Preheating Mode | IR Heating |
Preheating Area | L500mm*W500mm |
Soldering Precision | ±0.25 mm |
Soldering monitoring | CCD |
Solder Capacity | 12Kg |
Max PCB Size | 500*500mm |
Max PCB Size | 60mm |
PCB Thickness | 0.5-6.0mm |
PCB Weight | <20Kg |
Operating System | Windows10 |
Power Supply | 220VAC±10%, 50/60HZ |
Dimension | L1400*W2580*H1722mm |
Weight | Approx:700kg |
| DIP Line Equipment List
Our DIP production line offers advanced tools for efficient and precise PCB assembly. The fully automated DIP line includes a DIP insertion line for accurate component placement, a wave loader for smooth PCB entry, a wave unloader for safe exit, and an assembly belt line for final checks. This high-quality PCB DIP production line ensures stable operation, reliable THT insertion, and cost-effective assembly, meeting diverse industry needs. With modular designs and global support from I.C.T, it boosts productivity for through-hole tasks.
| Customer Success Video
Our Vietnam customer visited I.C.T factory to inspect the selective PCB soldering machine for supplying a world-famous camera brand. Engineers demonstrated acceptance tests on sample PCBs, showing flux spray, preheating, and precise wave contact. They trained on PC programming, parameter setting, wave calibration, and auto-cleaning. Clients observed real-time CCD and high-quality joints. Hands-on covered maintenance and troubleshooting. The visit ensured smooth integration, highlighting I.C.T's expert global support in the pcb selective soldering machine application.
| Professional Service and Training
I.C.T provides installation, maintenance, support, training for secure use. 20 engineers analyze demands, plan programs, optimize processes in PCBA, DIP. Cover operations, adjustments. Training includes PC controls, traceability, upgrades. Factory visits like Vietnam offer hands-on. Serve 1600+ customers in 72 countries with quick responses. Remote assistance, spares maintain selective PCB soldering machine efficiency.
| Customer Praise
Clients praise engineers for patient, expert training in visits and installs. They commend selective PCB soldering machine for precise flux, stable waves, easy controls boosting yields. Secure packing avoids damage. Fast responses solve issues quickly. Reviews note higher pass rates, less dross. Reliable equipment and support build trust.
| Industry Certifications
I.C.T holds CE, RoHS, ISO9001, multiple patents. CE ensures safety, RoHS eco-materials, ISO9001 quality systems. Patents cover valves, pumps, calibration, laser. These validate safe, green, innovative selective PCB soldering machine.
| About I.C.T Company and Factory
Internal research and manufacturing in 12000m² facility. 89 employees, 20 engineers, 8 offices enable rapid expansion. Support electronics customers worldwide. Rigorous testing and quality management throughout. Complete factory planning, equipment, training, optimization for PCBA, SMT, DIP, coating, robots, assembly in off-line selective wave soldering machine process.
