| I.C.T PCB Off Line Conformal Coating Machine
The I.C.T PCB Off Line Conformal Coating Machine stands as an efficient solution for offline selective coating of PCBA. It combines straightforward programming with fast changeover times to support smooth production. This PCB conformal coating machine liquid adhesive handles board sizes ranging from 50x50mm to 450x460mm and offers movement ranges of X=450mm, Y=450mm, Z=100mm. Operators can freely create any spray path while the main screen shows the route in real time. The system supports mirroring, arraying, and copying of tracks so multiple boards need only one edited pattern. It automatically records output numbers and working times. The machine serves various sectors including power supplies, industrial controls, LED lighting, automotive electronics, communications, and medical equipment. As a reliable PCB glue coating machine, it integrates easily into existing lines and helps maintain a cleaner production environment.
| Feature
Transmission System
The transmission system in the PCB Off Line Conformal Coating Machine rests on a high-strength platform built for lasting stability. Imported servo motors and drivers provide consistent power across all movements. The servo and slide rail combination achieves excellent accuracy and repeatability in the X, Y, and Z directions. Protective covers keep the screw rod and rails free from dust, which simplifies regular maintenance. Flexible tank chains route all cables and tubes in an orderly manner. This design reduces unexpected stops and supports extended operation periods. It delivers the steady motion required for uniform coating results in demanding production settings.
Transport System
The transport system of the PCB Off Line Conformal Coating Machine uses a specialized chain mechanism to prevent board jams. Precise motor control manages speed and stopping points accurately. Cylinder clamps hold each PCB firmly in position throughout the process. Semi-automatic rail width adjustment allows boards to move in and out without difficulty. The reinforced rail structure handles heavy boards without bending or deformation. This setup increases line efficiency and reduces handling defects. It connects smoothly with loaders and unloaders for complete workflow integration.
Coating System
The coating system in the PCB Off Line Conformal Coating Machine features dual valves designed for complex board layouts. Modular construction lets operators change valve types quickly according to different adhesive requirements. Optional rotation and tilt functions help reach difficult areas under components. A built-in UV lamp provides immediate visual feedback during operation. CCD vision is available as an upgrade for higher positioning accuracy. The system supports fine atomization, wide coverage, and high-flow options. It minimizes material waste while creating consistent protective layers.
Control System
The control system of the PCB Off Line Conformal Coating Machine arranges components logically with clear labeling for easy maintenance. High-precision servo parts ensure stable performance under different loads. Convection air cooling manages heat effectively during continuous runs. The PC combined with motion control board improves overall reliability. Real-time data monitoring connects with factory systems when needed. This keeps error rates low and supports consistent coating quality.
Operator System
The operator system on the PCB Off Line Conformal Coating Machine completes new programs in under 10 minutes and job changes in less than 2 minutes using Windows 10. The intuitive software includes teaching functions and navigation support. It displays the working path in real time for straightforward adjustments. Optional CCD vision improves accuracy further. The platform adjusts in height to suit different operators comfortably. This shortens learning time and supports efficient daily operation.
Advanced Dual Valve Coating System
The valve coating system of the PCB Off Line Conformal Coating Machine uses dual heads to handle varied adhesive types and board complexities. Quick modular replacement allows fast switching between different valve bodies. Options like U-axis rotation and tilt improve access to challenging spots. Built-in UV inspection and optional CCD vision ensure quality control during spraying. Available valves cover precision dots for small components, wide fan patterns for larger surfaces, and high-flow delivery for thicker applications. This flexibility reduces waste and delivers uniform protection across different production needs.
| Specification
| Selective Conformal Coating Machines | ||||
| Model | I.C.T-T550 | I.C.T-T550U | I.C.T-T600 | I.C.T-T650 |
| Number of valves | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 2 head) | 4 (atomization valve 2 head, precision valve 2 head) |
| Control method | PC + Motion Control Card | |||
| Number of spindles | X, Y, Z | X, Y, Z,U | X, Y, Z | X, Y, Z |
| PCB size | 50*50~450*460mm | |||
| Spindle drive | Imported servo motor+ball screw module | |||
| Automatic cleaning of valves | with 5L Pressure Tank | |||
| Power supply | AC 220V±10%, 50/60HZ, 2.2KW | |||
| Dimension | L910*W1600*H1700mm | |||
| Net weight | 1000KG | |||
| Coating Line Equipment List
Our PCBA Coating Line offers advanced tools for efficient and precise circuit board protection. The fully automated coating line includes a selective coating machine for accurate application, a curing oven for durable finishes, AOI for quality checks, a lift and flipper for smooth handling, and a conveyor system for seamless production.
This high-quality PCBA Coating Line ensures stable operation, reliable dustproof, waterproof, and explosion-proof coating, meeting diverse industry needs. With modular designs and global support from I.C.T, it enhances productivity for protective coating tasks.
| Product Name | Purpose in PCBA Coating Line |
|---|---|
Selective Conformal Coating Machine | Applies precise protective coatings to circuit boards for dustproof, waterproof, and explosion-proof protection. |
Hardens coatings with IR or UV light, ensuring durable and strong protection. | |
Transports circuit boards smoothly through the coating line for efficient processing. | |
Provides and stores PCB for the production line, ensuring smooth input and output. | |
| Conformal coating AOI | Inspects coating quality and detects defects to ensure high standards. |
| Customer Success Video
Our engineer recently visited a major European manufacturer of automotive dashboards. The company had purchased a complete PCBA coating line built around the PCB Off Line Conformal Coating Machine, together with loaders, UV curing ovens, unloaders, selective wave soldering, and full AOI inspection. He carried out the installation and detailed debugging on site. Comprehensive training covered daily operation, routine maintenance, and common troubleshooting. During the trial production phase, he worked closely with the customer team to solve challenges and fine-tune the process. The result was a quick transition to stable, high-quality output. The video clearly shows the precise coating performance on complex automotive boards and smooth integration into their production flow.
| Services and Training
I.C.T goes far beyond single machines by delivering complete SMT factory solutions. We help customers with full line planning, equipment integration, and process optimization for PCBA coating lines. Our engineers provide hands-on training and long-term technical support to ensure maximum productivity. With over 25 years of experience and more than 1,600 successful projects worldwide, we focus on reducing risks and improving efficiency. From initial layout to ongoing maintenance, I.C.T stands as a reliable partner. Our global network and local service teams help factories achieve stable, high-quality production across different industries.
| What Clients Say
Customers frequently highlight the professionalism of I.C.T engineers and their quick response during on-site support. Many praise the reliable performance of our equipment in full SMT lines and the clear improvement in coating quality. They appreciate the safe packaging that protects machines during long-distance shipping. Fast technical assistance helps solve problems without major delays. Clients often mention how our solutions increase their overall output and reduce defects. The combination of strong machines and excellent service makes I.C.T a trusted choice for building or upgrading production facilities.
| Certifications and Standards
I.C.T maintains high standards across all equipment and factory solutions. Our machines meet CE safety requirements, RoHS environmental standards, and ISO9001 quality management systems. We hold multiple patents for key coating technologies. Every unit goes through strict testing before leaving the factory. These certifications reflect our commitment to safety, reliability, and environmental responsibility. Customers in automotive, medical, and industrial sectors rely on these qualifications when choosing complete SMT lines and coating solutions.
| About I.C.T Company and Factory
I.C.T has grown into a trusted provider of complete SMT factory solutions with more than 25 years of industry experience. We support customers from initial planning through equipment supply, installation, training, and ongoing optimization. Our own R&D and manufacturing base in China, combined with 8 international offices, allows us to serve over 1,600 customers in 72 countries. We focus on practical results and long-term partnerships. Whether building a new line or upgrading existing production, I.C.T delivers reliable technology and comprehensive support. Our goal remains helping manufacturers achieve higher efficiency and consistent quality across all processes.
