| SMT PCB Printing Machine
The PCB Printing Machine I.C.T-4034 handles PCBs up to 400x340mm with 7-second cycles. Repeat accuracy ±0.01mm and print precision 0.025mm suit LED and automotive needs. Auto PCB calibration, pressure balance, and stencil cleaning cut manual steps. It supports glue for LED Solder Paste Printer applications. The china printing machine uses Windows 10 for simple control. Industry 4.0 and MES allow real-time monitoring. I.C.T offers full training and optimization. Contact for pcb printer machine price details.
| Feature
Arch bridge suspension links squeegee directly with two motors. This controls pressure on both sides accurately. Slide rails keep stability before and after printing. Real-time feedback ensures perfect paste formation. The PCB Printing Machine fits fine-pitch LED boards. Imported Japanese and German parts reduce failures. Low downtime over ten years service life. It saves solder and boosts yield in high-volume lines. Auto separation methods prevent damage to stencil or PCB.
Belt system prevents jams with precise motor speed up to 1500mm/s. Directions switch left-right or right-left freely. Side clamps and vacuum hold boards with warpage under 1%. This guarantees smooth contact for quality prints. The china printing machine supports magnetic pins and up-down tables. Stop positions are exact for fast changeover under 5 minutes. It handles PCB thickness 0.4-6mm manually or auto. Reliable for pcb printer machine price value.
Dry, wet, vacuum modes clean stencil completely. Separate CCD and spray design spreads alcohol evenly. Software controls paper and liquid to cut costs. Strong exhaust removes residue fast. The LED Solder Paste Printer maintains high quality over long production. Manual option adds flexibility. This prevents defects from dirty stencils. Easy maintenance keeps efficiency high.
| Specification
| Model | I.C.T-4034 | I.C.T5134 | I.C.T-5151 |
| Frame Size(mm) | 470*370 ~ 737*737 | 470*370 ~ 737*737 | 470*370 ~ 737*737 |
| PCB Size(mm) | 50*50 ~ 400*340 | 50*50 ~ 510*340 | 50*50 ~ 510*510 |
| Transport Direction | Left-Right; Right-Left; Left-Left; Right-Right | ||
| Support System | Magnetic Pin/Up-down table adjusted/support block | ||
| Clamping System | Side clamping(vacuum nozzle,Automation retractable Z pressure is option) | ||
| Printer Head | Two independent motorised printhead | ||
| Squeegee Type | Stainless steel(standard),plastic | ||
| Cleaning System | Dry, Wet, Vacuum | ||
| Inspection | 2D Inspection(Standard) | ||
| Power Supply | AC:220±10%,50/60HZ,3Kw | ||
| Control Method | PC Control | ||
| Dimension(mm) | 1220*1355*1500 | 1220*1355*1500 | 1220*1550*1500 |
| Model | I.C.T-6534 | I.C.T-6561 | I.C.T-9060 |
| Frame Size(mm) | 650*400 ~ 850*750 | 650*400 ~ 850*850 | 737*400 ~ 1100*900 |
| PCB Size(mm) | 50*50 ~ 650*340 | 80*50 ~ 650*610 | 80*50 ~ 900*600 |
| Dimension(mm) | 1330*1370*1500 | 1330*15450*1500 | 1580*1545*1500 |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
Our High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
| Customer Success Case Study Video
I.C.T sent engineers to North America for a beauty instrument factory. They installed two SMT lines featuring the PCB Printing Machine. Setup involved full calibration, testing, and alignment checks. Local team received training on auto calibration, pressure settings, and MES integration. Lines achieved quick acceptance with high precision for small components. Client appreciated rapid issue resolution and process tips. This demonstrates I.C.T global expertise and reliable support for international projects.
| Global Service and Training Support
I.C.T provides complete installation, upkeep, and training for the PCB Printing Machine. On-site experts handle setup, calibration, and line optimization. Remote diagnostics fix faults quickly. Training includes interface use, log analysis, and program setup in 5-10 minutes. We adapt to production changes for better output. Worldwide centers stock parts for fast delivery. Long-term partnership ensures smooth operation and upgrades. Inquire about pcb printer machine price with service packages.
| Customer Reviews
Users praise I.C.T engineers for professional overseas installation and prompt responses. The PCB Printing Machine offers stable performance with minimal breakdowns. Safe packing arrives intact globally. Quick solutions maintain production flow. One LED maker said, "Precision improved our assembly greatly." Another valued easy training and cost savings. Reliable for china printing machine needs.
| Certifications and Standards
I.C.T complies with CE, RoHS, ISO9001 for safety and environment. Patents cover arc cleaning, pressure control, collision prevention, and transport systems. These innovations ensure top print quality and stencil life. Global standards build buyer confidence.
| About I.C.T Company and Our SMT Factory
I.C.T develops and produces in-house with 89 staff and 20 engineers. We serve over 1600 customers in 72 countries with rapid growth. Strict quality tests and management cover full SMT lines. Global sales and service centers provide local help. This supports reliable PCB Printing Machine and total solutions.
