Name: I.C.T-P3 | Semi-Auto SMT Dual Squeegee PCB Printer with High Precision
Brand: I.C.T
Rating: 5.0 (15 reviews)

I.C.T | Semi-Auto SMT Dual Squeegee PCB Printer with High Precision

Overview

Introduce:

1. Using linear guide-ways,matching motor drive speed , ensure the printing stability and precision.

2. Blade pressure and printing speed is adjustable,precision pressure gauge, speed controller display.

3. Suspension blade system makes printing more evenly.

4. Modular universal bench, thimble random placement , easy conversion.

5. With alignment device for PCB board and frame.

6. Work with both single-sided and double-sided PCB boards.

7. Steel frame arms can be adjusted for different size ranges from 370 * 470mm to 1500 * 350mm .

8. Auto printing , stable and efficient printing quality.

Features：

Platform system

The pin and support block shall be suitable for different one-sided and double-sided PCB, and the pin of different sizes shall be suitable for different PCB holes. operation simple, the positioning is accurate, and the fixed position is flexible and adjustable.

Drive system

Imported stepper motor, Taiwan precision guide rail ensures stability, squeegee system can be lifted by manual, convenient to add solder paste and cleaning operation, limit sensor flexible adjustment to reduce transportation travel.

Print system

Direct connection squeegee structure.The squeegee is

independently controlled by two high-precision cylinder to ensure accurate and stable pressure.The double slide positioning rails ensure the accuracy and stability of the squeegee.

Control system

Touch screen operation,friendly english MMI interface, teaching and navigation function. Operation mode: manual, semi-automatic and full-automatic .The core control parts adopt imported high-quality brands to ensure the stability and operability of the printer.

Specification

Model	P3	P6	P12	P15
Accuracy	+/- 0.05mm	+/- 0.05mm	+/- 0.05mm	+/- 0.05mm
PCB Size	300 x 350 mm	600 x 350 mm	1200 x 350 mm	1500 x 350 mm
Platform size	320 x 400 mm	700 x 400 mm	1350 x 400 mm	1650 x 400 mm
Stencil Size(mm)	370470-550650	370470-550650	370470-1500650	370470-1750650
PCB Thickness	0.2 - 6 mm	0.2 - 6 mm	0.2 - 6 mm	0.2 - 6 mm
Stencil Positioning	Manual	Manual	Manual	Manual
Cycle Time	< 10 Sec.	< 10 Sec.	< 12 Sec.	< 12 Sec.
Power Consumption	200 W	200 W	220 W	220 W
Power Supply	1 -PH, 220VAC 50/60HZ	1 -PH, 220VAC 50/60HZ	1 -PH, 220VAC 50/60HZ	1 -PH, 220VAC 50/60HZ
Air Pressure	4.5-6 kg/cm	4.5-6 kg/cm	4.5-6 kg/cm	4.5-6 kg/cm
Squeegee Speed	0-200mm/sec	0-1200mm/sec	0-200mm/sec	0-200mm/sec
Dimension	850x750x1650 mm	1050x750x1650 mm	1660x750x1650 mm	2100x750x1650 mm
Weight	280 Kg	300 Kg	356 Kg	430 Kg
Squeegee Length	250mm	250mm	250mm	250mm
Platform Height	950mm	950mm	950mm	950mm
Option: Special size can be customized

* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.

FAQ:

Q: What is SMT stencil printer?

A: A Surface Mount Technology (SMT) stencil printer is a specialized machine used in electronics manufacturing. It is designed to precisely apply solder paste onto printed circuit boards (PCBs) through a stencil. This precise deposition of solder paste is crucial for the accurate placement of surface-mount components during the SMT assembly process, ensuring reliable electrical connections and optimal performance of electronic devices.

Q: What does a stencil machine do?

A: A stencil machine is used in SMT (Surface Mount Technology) assembly to precisely deposit solder paste or adhesive onto PCBs, ensuring accurate placement of components during electronics manufacturing.

Q: What are the disadvantages of stencil printing?

A: Disadvantages of stencil printing in SMT include the need for periodic stencil replacement, potential solder paste smearing, and challenges with fine-pitch components due to limited accuracy.

Q: What type of machine makes stencils?

A: Stencils used in SMT are typically manufactured by laser-cutting or chemical etching processes, often performed by specialized stencil manufacturers.

These succinct answers can be placed in your product's details page FAQ section to enhance your website's Google search visibility.
