| I.C.T PCBA Conaformal Coating Machine
The I.C.T pcba conaformal coating machine is the new benchmark for simple and efficient PCBA coating processes in modern electronics manufacturing. Its easy program making and fast line change settings bring the best results in all directions while meeting various industry needs. It is widely used in the fields of drive power, industrial control, LED, automotive electronics, communication, instrumentation, consumer electronics, electronic appliances, military, and medical boil, etc. PCB Size: 5050~450460mm.
Programming can edit any spraying trajectory, and the main interface displays the spraying path beautifully for verification. The running track can be mirrored, arrayed, and copied—for multiple boards, you only need to edit one track, which is quick and convenient. Automatically count and display production data, output, single product working time, etc. As a reliable pcb production line coating machine, it integrates seamlessly into full SMT lines for enhanced productivity and quality control.
| Feature
Transmission System
The transmission system of the pcba conaformal coating machine features a high-strength working platform to ensure the stability of the machine during continuous high-speed operations. It uses imported servo motors and drivers for reliable and consistent power delivery. The servo motor + slide rail design module ensures the repeatability and accuracy of X/Y/Z axes movements with minimal deviation.
A unique dust cover design ensures the cleanliness of the screw rod and slide rail, reducing the complexity of maintenance and preventing dust buildup. Highly flexible tank chain makes each pipeline and line neat and beautiful while avoiding tangles. This setup lowers overall downtime, supports 24/7 production runs, and reduces long-term ownership costs effectively. In the context of a pcb production line coating machine, it enables perfectly uniform coating layers, raising production yields by up to 15% through precise motion control.
Transport System
The transport system of the pcba conaformal coating machine employs a unique chain conveying system that effectively prevents PCB from getting stuck or damaged during transfer. Motor controls speed and stops precisely to maintain smooth and controlled board movement. Cylinder clamping ensures that PCB will not shift during the entire operation process, providing secure holding.
The width of the guide rail can be adjusted semi-automatically, allowing PCB to enter and exit freely without manual interference. The rail designed with chains and profiles can also bear heavy PCB without deformation over extended use. This boosts overall throughput by 25% and significantly reduces defect rates in production. It integrates effortlessly with upstream loaders and downstream unloaders in a pcb production line coating machine setup. Tool-free adjustments and jam-free operation suit high-mix environments perfectly. Safety sensors are included to guarantee zero accidents and operator peace of mind.
Coating System
General features of the pcba conaformal coating machine include an imported precision air pressure regulator equipped with a digital pressure gauge for consistent and accurate spray control. The humanized operation panel is designed to improve the work efficiency of operators by providing intuitive icons and quick access.
The conveyor rail is hardened and equipped with stainless steel wear-resistant strips to extend the life of the rail significantly. Rail width adjustment adopts a synchronous belt transmission mechanism to ensure accurate rail transportation and reliable board handling. An independent pure steel gantry improves overall track machine stability and resists external vibrations. Install air curtains at the entrance and exit to avoid gas leakage and improve the workshop environment by maintaining cleaner air. These elements combine to offer versatile and precise performance in the pcb production line coating machine.
Control System
The control system for the pcba conaformal coating machine adopts a reasonable layout with standardized labeling, making inspection and maintenance easy and straightforward for technicians. High-precision servo control components ensure stable operation even under varying loads and conditions.
The heat dissipation design uses convection cooling of air to prevent overheating during prolonged runs. PC+control board mode greatly improves system stability and fault tolerance against electrical issues. Real-time monitoring can be integrated with MES for data-driven insights and traceability. This keeps error rates under 0.5% in demanding applications of the pcb production line coating machine.
Remote troubleshooting capabilities save valuable time on diagnostics. It achieves perfect coordination between valves and lamps for consistent IP67-level protection. Additionally, the energy-efficient design saves up to 20% power compared to traditional systems.
Operator System
The operator system in the pcba conaformal coating machine allows a new program to be controlled in under 10 minutes and change over in less than 2 minutes, based on the familiar Windows 10 platform. User-friendly software includes teaching and navigation functions to guide users step by step. Real-time display of the working path makes operation simple and intuitive, reducing guesswork.
CCD vision is available as an option for enhanced positioning precision. The operating platform is adjustable and can flexibly adapt to different operators' heights and preferences, minimizing fatigue. This shortens the overall training period to just one shift even for newcomers in a pcb production line coating machine environment. Multi-language support and built-in video tutorials ensure usability for global teams. The touchscreen interface further minimizes operational errors effectively.
Advanced Dual Valve Coating System
The coating system in the pcba conaformal coating machine uses a dual valve design that is suitable for more complex PCBA and varied application scenarios requiring flexibility. Modular design allows quick replacement of different valve bodies for different products in under 2 minutes. Optional U-axis and tilt make coating easy even for complex PCBA shapes with hard-to-reach areas.
Built-in UV lamp for intuitive visual working status during operation. CCD vision is an option for sub-millimeter accuracy. Specific valves include H-808 for fine atomized dots on small parts with low overspray, H-818 for wide fan films on larger areas, and H-828 for high-flow thick layers. This reduces material waste by 20-30% and supports low-VOC materials effectively. It delivers uniform IP67-level guard in the pcb production line coating machine for enhanced product reliability.
| Specification
| Selective Conformal Coating Machines | ||||
| Model | I.C.T-T550 | I.C.T-T550U | I.C.T-T600 | I.C.T-T650 |
| Number of valves | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 2 head) | 4 (atomization valve 2 head, precision valve 2 head) |
| Control method | PC + Motion Control Card | |||
| Number of spindles | X, Y, Z | X, Y, Z,U | X, Y, Z | X, Y, Z |
| PCB size | 50*50~450*460mm | |||
| Spindle drive | Imported servo motor+ball screw module | |||
| Automatic cleaning of valves | with 5L Pressure Tank | |||
| Power supply | AC 220V±10%, 50/60HZ, 2.2KW | |||
| Dimension | L910*W1600*H1700mm | |||
| Net weight | 1000KG | |||
| Coating Line Equipment List
Our PCBA Coating Line offers advanced tools for efficient and precise circuit board protection. The fully automated coating line includes a selective coating machine for accurate application, a curing oven for durable finishes, AOI for quality checks, a lift and flipper for smooth handling, and a conveyor system for seamless production.
This high-quality PCBA Coating Line ensures stable operation, reliable dustproof, waterproof, and explosion-proof coating, meeting diverse industry needs. With modular designs and global support from I.C.T, it enhances productivity for protective coating tasks.
| Product Name | Purpose in PCBA Coating Line |
|---|---|
Applies precise protective coatings to circuit boards for dustproof, waterproof, and explosion-proof protection. | |
Hardens coatings with IR or UV light, ensuring durable and strong protection. | |
Transports circuit boards smoothly through the coating line for efficient processing. | |
Provides and stores PCB for the production line, ensuring smooth input and output. | |
| Conformal coating AOI | Inspects coating quality and detects defects to ensure high standards. |
