| Smt Lead-Free Wave Soldering Machine – Professional Soldering Wave Machine
I.C.T W-series Smt Lead-Free Wave Soldering Machine is the core soldering dip machine for SMT DIP production lines. This smt soldering machine uses Japanese Kuroda precision nozzle for accurate flux coating, fully independent horizontal heating zones for stable temperature control, and energy-saving design that keeps normal power at only 7kW. Optional nitrogen protection meets high-quality lead-free standards. Widely applied in automotive electronics, smart meters and consumer products, this Smt Lead-Free Wave Soldering Machine offers outstanding performance for modern SMT DIP lines.
| Feature
Japanese Kuroda nozzle with adjustable atomizing area and pyramid filter deliver uniform, low-consumption flux layer every cycle. Digital flow meter and stable pressure tank reduce flux usage by half and keep the chamber clean – a major advantage for Smt Lead-Free Wave Soldering Machine in continuous THT production.
Third-party independent over-temperature protection plus PLC+PID closed-loop control provide multiple safety layers. Real-time monitoring and instant emergency stop protect operators and equipment during 24-hour operation of DIP Wave Soldering Machine.
Independent horizontal heating zones with closed hot-air path and rectifier plates guarantee perfectly even temperature across the whole board. Warm-up takes only about 15 minutes and normal power stays at 7kW – the most economical heating among similar Soldering Wave Machine.
| DIP Line Equipment List
| Model | W4 | W3 | W2 |
| Dimension:(mm) | 4200X1250X1500 | 3600X1250X1500 | 2900X1160X1500 |
| Weight(kg) | Approx.1500kg | Approx.1200kg | Approx.790kg |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 32kw | 24kw | 16kw |
| Operation Power | 12kw | 9kw | 7kw |
| Control System | PLC | ||
| Spray System | |||
| Transmission Method | Step motor | ||
| Spray Pressure | 0.25Mpa--0.4Mpa | ||
| lux flow | 10--100ml/min | ||
| Exhaust Diameter | Φ200mm | ||
| Exhaust Capacity | 25m3/min | ||
| Preheating System | |||
| Preheating Mode | Hot air | ||
| Control Mode | PID + SSR | ||
| Preheating Zone | 4 | 3 | 2 |
| Preheating Length | 1800mm | 1600mm | 1200mm |
| Preheating Temp. | (Room Temperature)-250°C | ||
| Warm-up Time(min) | Approx.15min (setting 150°C) | ||
| Conveyor System | |||
| PCB Size:LxW(mm) | Min:80x60mm; Max:400x300mm | ||
| Conveyor Speed | 0-2000(mm/min) | ||
| Conveyor Height | 750+/-20 (mm) | ||
| Finger | Double hook claw (Standard) | ||
| Conveyor width control | Manually | ||
| Conveyor Angle | 4~7degree | ||
| Soldering System | |||
| Solder Pot style | Mechanical Motor drive | ||
| Solder Pot Material | Full Titanium (Standard FT) | ||
| Solder pot temperature | 300°C | ||
| Solder pot capacity | Lead-free 350kg | Lead-free 300kg | Lead-free 250kg |
| Other | |||
| Finger cleaning system | Brush | ||
