| Automated Wave Soldering Machine – Made in China
The I.C.T W-series automated wave soldering machine is a high-performance automatic wave soldering machine developed and manufactured in China for DIP and THT production lines. This china automatic wave soldering machine integrates Japanese Kuroda precision nozzle, fully independent horizontal heating and advanced energy-saving technology to achieve excellent through-hole wetting with extremely low oxidation. Normal running power is only 7kW while optional nitrogen protection meets the strictest environmental standards. Widely applied in automotive electronics, smart meters and industrial control systems, this lead free wave solder machine offers outstanding wave soldering machine cost advantage and has become the preferred choice for customers building high-efficiency automatic wave soldering machine lines.
| Feature
Japanese Kuroda nozzle with adjustable atomizing range and pyramid filter ensure stable, low-waste flux coating every cycle. Digital flow meter and constant pressure supply keep the furnace interior clean and greatly reduce flux consumption – a major benefit for china automatic wave soldering machine in continuous THT production.
Third-party independent over-temperature protection combined with PLC+PID closed-loop control create multiple safety mechanisms. Real-time monitoring and instant emergency shutdown protect operators and the entire automatic wave soldering machine during 24-hour operation.
Fully independent horizontal heating zones with closed hot-air path and rectifier plates deliver perfectly even temperature across the whole board. Warm-up time is only about 15 minutes and normal power consumption stays at 7kW – the most cost-effective heating performance among similar lead free wave solder machine.
| DIP Line Equipment List
| Model | W4 | W3 | W2 |
| Dimension:(mm) | 4200X1250X1500 | 3600X1250X1500 | 2900X1160X1500 |
| Weight(kg) | Approx.1500kg | Approx.1200kg | Approx.790kg |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 32kw | 24kw | 16kw |
| Operation Power | 12kw | 9kw | 7kw |
| Control System | PLC | ||
| Spray System | |||
| Transmission Method | Step motor | ||
| Spray Pressure | 0.25Mpa--0.4Mpa | ||
| lux flow | 10--100ml/min | ||
| Exhaust Diameter | Φ200mm | ||
| Exhaust Capacity | 25m3/min | ||
| Preheating System | |||
| Preheating Mode | Hot air | ||
| Control Mode | PID + SSR | ||
| Preheating Zone | 4 | 3 | 2 |
| Preheating Length | 1800mm | 1600mm | 1200mm |
| Preheating Temp. | (Room Temperature)-250°C | ||
| Warm-up Time(min) | Approx.15min (setting 150°C) | ||
| Conveyor System | |||
| PCB Size:LxW(mm) | Min:80x60mm; Max:400x300mm | ||
| Conveyor Speed | 0-2000(mm/min) | ||
| Conveyor Height | 750+/-20 (mm) | ||
| Finger | Double hook claw (Standard) | ||
| Conveyor width control | Manually | ||
| Conveyor Angle | 4~7degree | ||
| Soldering System | |||
| Solder Pot style | Mechanical Motor drive | ||
| Solder Pot Material | Full Titanium (Standard FT) | ||
| Solder pot temperature | 300°C | ||
| Solder pot capacity | Lead-free 350kg | Lead-free 300kg | Lead-free 250kg |
| Other | |||
| Finger cleaning system | Brush | ||
| DIP Line Equipment List
Our DIP production line offers advanced tools for efficient and precise PCB assembly. The fully automated DIP line includes a DIP insertion line for accurate component placement, a wave loader for smooth PCB entry, a wave unloader for safe exit, and an assembly belt line for final checks. This high-quality PCB DIP production line ensures stable operation, reliable THT insertion, and cost-effective assembly, meeting diverse industry needs. With modular designs and global support from I.C.T, it boosts productivity for through-hole tasks.
| Customer Success Video
I.C.T engineers traveled to Uruguay to install and commission the W-series automated wave soldering machine for a smart meter manufacturer. The customer operates a high-volume DIP production line and required stable lead-free soldering for complex PCBs with large components. After our team finished installation and operator training, the machine reached full production speed with only 7kW running power and excellent joint quality. The customer released a video showing the automated wave soldering machine operating smoothly in their THT assembly line, highlighting the low energy consumption, simple maintenance and outstanding after-sales support. This Uruguay smart meter project has become a benchmark case for many Latin American DIP lines.
| Expert Services and Training
I.C.T provides complete lifecycle service for every automated wave soldering machine – from factory layout design and professional installation to comprehensive operator training and 7×24 global technical support. Our experienced engineers ensure your china automatic wave soldering machine and entire THT line achieve maximum productivity and minimum wave soldering machine cost with zero risk.
| Customer Praise
Customers worldwide praise our automated wave soldering machine for its exceptional stability, extremely low electricity consumption and perfect soldering results on complex boards. They particularly value the rapid global response, strong export packaging and the best wave soldering machine cost performance among similar automatic wave soldering machine.
| Quality Certifications
Every I.C.T automated wave soldering machine carries CE, CCC, UL, RoHS and ISO9001 certifications plus several invention patents, fully meeting the highest international safety and environmental standards for modern DIP production lines.
| About I.C.T Company and Factory
I.C.T is a professional one-stop solution provider for SMT and DIP production lines with over 25 years of experience. Our 12,000㎡ factory in Dongguan employs 89 staff including 20 engineers. We design and manufacture all core equipment in-house and serve more than 1600 customers across 72 countries. Strict quality management and continuous innovation make us the most trusted partner for high-performance lead free wave solder machine worldwide.
