| DIP Wave Solder Equipment for High-Volume PCBA Assembly
I.C.T W-series DIP Wave Solder Equipment is the reliable heart of modern DIP production lines and THT assembly lines. This advanced DIP Wave Solder Equipment for PCBA Assembly uses Japanese Kuroda precision nozzle with Wave Soldering Machine With Flux, fully independent horizontal heating and intelligent energy-saving technology to deliver excellent through-hole joints with minimum dross. Normal running power is only 7kW while optional nitrogen protection meets strict quality requirements. After years of successful use in automotive, smart meter and industrial electronics factories, this DIP Wave Solder Equipment offers the most competitive wave soldering machine price for customers building efficient PCBA lines.
| Feature
Japanese Kuroda Seiko nozzle with adjustable atomizing area and pyramid filter provide stable and economical Wave Soldering Machine With Flux application every cycle. Digital flow control and constant pressure valve greatly reduce waste and keep the chamber clean – a major cost-saving feature for DIP Wave Solder Equipment in continuous PCBA assembly.
Third-party independent over-temperature protection plus PLC+PID closed-loop control create multiple safety barriers. Real-time monitoring and instant emergency stop safeguard operators and equipment during 24-hour operation of DIP Wave Solder Equipment for PCBA Assembly.
Fully independent horizontal heating zones with closed hot-air path and rectifier plates ensure perfectly uniform temperature across every board. Warm-up time is only about 15 minutes and normal power stays at 7kW – the most efficient heating among similar DIP Wave Solder Equipment, giving customers the best wave soldering machine price advantage.
| DIP Line Equipment List
| Model | W4 | W3 | W2 |
| Dimension:(mm) | 4200X1250X1500 | 3600X1250X1500 | 2900X1160X1500 |
| Weight(kg) | Approx.1500kg | Approx.1200kg | Approx.790kg |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 32kw | 24kw | 16kw |
| Operation Power | 12kw | 9kw | 7kw |
| Control System | PLC | ||
| Spray System | |||
| Transmission Method | Step motor | ||
| Spray Pressure | 0.25Mpa--0.4Mpa | ||
| lux flow | 10--100ml/min | ||
| Exhaust Diameter | Φ200mm | ||
| Exhaust Capacity | 25m3/min | ||
| Preheating System | |||
| Preheating Mode | Hot air | ||
| Control Mode | PID + SSR | ||
| Preheating Zone | 4 | 3 | 2 |
| Preheating Length | 1800mm | 1600mm | 1200mm |
| Preheating Temp. | (Room Temperature)-250°C | ||
| Warm-up Time(min) | Approx.15min (setting 150°C) | ||
| Conveyor System | |||
| PCB Size:LxW(mm) | Min:80x60mm; Max:400x300mm | ||
| Conveyor Speed | 0-2000(mm/min) | ||
| Conveyor Height | 750+/-20 (mm) | ||
| Finger | Double hook claw (Standard) | ||
| Conveyor width control | Manually | ||
| Conveyor Angle | 4~7degree | ||
| Soldering System | |||
| Solder Pot style | Mechanical Motor drive | ||
| Solder Pot Material | Full Titanium (Standard FT) | ||
| Solder pot temperature | 300°C | ||
| Solder pot capacity | Lead-free 350kg | Lead-free 300kg | Lead-free 250kg |
| Other | |||
| Finger cleaning system | Brush | ||
| DIP Line Equipment List
Our DIP production line offers advanced tools for efficient and precise PCB assembly. The fully automated DIP line includes a DIP insertion line for accurate component placement, a wave loader for smooth PCB entry, a wave unloader for safe exit, and an assembly belt line for final checks. This high-quality PCB DIP production line ensures stable operation, reliable THT insertion, and cost-effective assembly, meeting diverse industry needs. With modular designs and global support from I.C.T, it boosts productivity for through-hole tasks.
| Customer Success Video
I.C.T engineers went to Uruguay to install and commission the W-series DIP Wave Solder Equipment for a smart meter manufacturer. The customer runs a high-volume DIP production line and needed stable lead-free soldering for complex PCBs with large parts. After our team completed the setup and operator training, the machine reached full speed with only 7kW running power and perfect joint quality. The customer shared a video showing the DIP Wave Solder Equipment running smoothly in their THT assembly line, praising the low energy cost, easy maintenance and excellent after-sales support. This Uruguay smart meter project has become a successful reference for many Latin American DIP lines.
| Expert Services and Training
I.C.T provides complete support for every DIP Wave Solder Equipment – from factory layout design and professional installation to detailed operator training and 7×24 global technical assistance. Our experienced engineers ensure your DIP Wave Solder Equipment for PCBA Assembly and entire THT line operate at maximum efficiency with minimum downtime.
| Customer Praise
Customers worldwide praise our DIP Wave Solder Equipment for its outstanding stability, extremely low electricity consumption and perfect soldering results on complex boards. They especially highlight the fast global response, strong export packaging and the most competitive wave soldering machine price among similar DIP Wave Solder Equipment for PCBA Assembly.
| Quality Certifications
Every I.C.T DIP Wave Solder Equipment carries CE, CCC, UL, RoHS and ISO9001 certifications plus several invention patents, fully meeting the strictest international safety and environmental standards for modern PCBA assembly lines.
| About I.C.T Company and Factory
I.C.T is a professional one-stop solution provider for SMT and DIP production lines with over 25 years of experience. Our 12,000㎡ factory in Dongguan employs 89 staff including 20 engineers. We design and manufacture all core equipment in-house and serve over 1600 customers across 72 countries. Strict quality management and continuous innovation make us the most reliable partner for high-performance DIP Wave Solder Equipment worldwide.
