I.C.T-T550
I.C.T
smt pcb metal coating machines
| Quantity: | |
|---|---|
| I.C.T Coating Spraying Gluing Machine for PCB
The I.C.T PCB automatic selective coating machine sets a high standard for easy PCBA protection. It uses simple programming and quick setup changes to give top results. Users edit spray routes freely, with screen showing paths clear. For many boards, it copies or mirrors tracks fast. It tracks output and time auto. The PCB automatic selective coating machine works in power drives, industrial controls, LED lights, car electronics, and more. It meets all needs with strong speed and low waste.
| Feature
Transmission System
The transmission system in the PCB automatic selective coating machine starts with a strong platform that keeps it steady during runs. It uses imported servo motors and drivers for smooth power. Servo plus slide rail setup gives exact X/Y/Z moves and high repeat. Special dust cover protects screw and rail from dirt, so maintenance stays simple. Flexible tank chains keep pipes and wires neat and safe. This design cuts breakdowns and helps the machine run reliably in busy factories. Overall, it supports precise work for long hours without issues in the coating spraying gluing machine for PCB.
Transport System
The transport system in the PCB automatic selective coating machine uses special chain to stop boards from sticking or jamming. Motors control speed and stops with great care. Cylinder clamps hold PCBs tight so they don't shift mid-process. Guide rail width changes semi-auto, letting boards enter and leave with ease. Chains and profiles take heavy boards without bend. This setup keeps smooth flow and boosts daily output. It fits well for high-volume lines.
Coating System
The coating system has dual valves for tough PCBA jobs in the PCB automatic selective coating machine. Modular parts swap valves fast for different tasks. H-808 does fine dots on small parts in LEDs. H-818 fans wide films on car boards. H-828 flows high for thick layers in power units. Optional U-axis turns 360° and tilts 45° to coat hard spots. UV lamp checks spray live, CCD adds spot-on aim. This cuts waste by 20-30% and gives even IP67 protection.
Control System
The control system arranges parts smartly with clear labels for fast checks and fixes in the PCB automatic selective coating machine. It uses high-precision servo parts for steady runs. Heat spread design with air flow cools it well. PC plus control board mode raises trust. This keeps operations smooth and error-free. It links to full SMT lines without hassle.
Operator System
The operator system sets new programs in under 10 minutes and changes lines in less than 2 on Windows 10. Friendly software guides users with easy steps and tips. It shows work paths live for clear views. CCD vision helps as add-on. Platform adjusts height for all users. This makes the PCB automatic selective coating machine simple to learn and use daily. It saves time and cuts training needs.
Advanced Dual Valve Coating System
The valve system in the coating spraying gluing machine for PCB has dual design for complex jobs. Modular swap takes under 2 minutes for different valves. H-808 does fine dots for small parts in LED and gadgets. H-818 fans wide films for car boards. H-828 flows high for thick layers in power units. Optional U-axis turns 360° and tilts 45° to reach under parts. UV lamp checks live, CCD aims ±0.05mm. It cuts waste 20-30% and gives even IP67 guard.
| Specification
| Selective Conformal Coating Machines | ||||
| Model | I.C.T-T550 | I.C.T-T550U | I.C.T-T600 | I.C.T-T650 |
| Number of valves | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 2 head) | 4 (atomization valve 2 head, precision valve 2 head) |
| Control method | PC + Motion Control Card | |||
| Number of spindles | X, Y, Z | X, Y, Z,U | X, Y, Z | X, Y, Z |
| PCB size | 50*50~450*460mm | |||
| Spindle drive | Imported servo motor+ball screw module | |||
| Automatic cleaning of valves | with 5L Pressure Tank | |||
| Power supply | AC 220V±10%, 50/60HZ, 2.2KW | |||
| Dimension | L910*W1600*H1700mm | |||
| Net weight | 1000KG | |||
| Coating Line Equipment List
Our PCBA Coating Line offers advanced tools for efficient and precise circuit board protection. The fully automated coating line includes a selective coating machine for accurate application, a curing oven for durable finishes, AOI for quality checks, a lift and flipper for smooth handling, and a conveyor system for seamless production.
This high-quality PCBA Coating Line ensures stable operation, reliable dustproof, waterproof, and explosion-proof coating, meeting diverse industry needs. With modular designs and global support from I.C.T, it enhances productivity for protective coating tasks.
| Product Name | Purpose in PCBA Coating Line |
|---|---|
Applies precise protective coatings to circuit boards for dustproof, waterproof, and explosion-proof protection. | |
Hardens coatings with IR or UV light, ensuring durable and strong protection. | |
Transports circuit boards smoothly through the coating line for efficient processing. | |
Provides and stores PCB for the production line, ensuring smooth input and output. | |
| Conformal coating AOI | Inspects coating quality and detects defects to ensure high standards. |
| Customer Success Video
Our engineer went to Europe for SMT help in car electronics. The client builds dashboards and got a full set from I.C.T, including the PCB automatic selective coating machine in a coating line with loader, UV oven, and unloader. They also added wave soldering and AOI checks. The engineer set up and tuned all gear on site. He taught staff how to run, fix, and care for it. In trial runs, he fixed flow issues and tuned for top quality. This let the client start strong production fast. The video captures the install and smooth coating demo.
| Services and Training
I.C.T gives complete install and upkeep for the PCB automatic selective coating machine. Our pros train teams on setup, daily use, and quick fixes. We answer calls fast with remote help or site visits. Lessons cover program edits and clean routines. We stock parts for easy access. This builds client skills and keeps lines running well. Long-term, we check and update to match needs. It lowers risks and raises value from day one.
| What Clients Say
Clients cheer our engineers for smart fixes and quick trips. They rate the PCB automatic selective coating machine high for even sprays and speed. Packing stays safe in transit with no damage. We reply to questions in hours, easing worries. Strong builds lift their output daily. Many say it's their top pick for reliability in the coating spraying gluing machine for PCB.
| Certifications and Standards
I.C.T earns CE, RoHS, and ISO9001 approvals for safe, green gear. We hold patents on key tech like valve swaps. All machines pass tough tests before ship. This backs top standards in every unit.
| About I.C.T Company and Factory
I.C.T leads with in-house R&D and builds, backed by 89 skilled staff. Since 2012, we've grown fast with $30M funds and 8 branches. Over 1600 clients in 72 nations count on us. Factories use strict checks and quality systems for flawless output. Globalization and localization drive our cross-value platform in electronics manufacturing.
