| Wave Soldering Machine for PCBs – Heat Wave Soldering Solution
I.C.T W-series Wave Soldering Machine for PCBs is a practical and proven pcb soldering machine specially made for DIP production lines and THT assembly lines. This heat wave soldering machine uses Japanese Kuroda precision nozzle to place flux exactly where needed, independent horizontal heating zones to build a perfect temperature curve, and smart power management to keep daily consumption at just 7kW. Optional nitrogen protection meets strict lead-free standards. After years of daily use in automotive electronics, smart meters and home appliances, this Wave Soldering Machine for PCBs has become the trusted machine soldering pcb choice for factories that need stable performance every shift.
| Feature
Japanese Kuroda nozzle with adjustable atomizing area and pyramid filter place a thin, uniform flux layer on every board. Digital flow meter and constant pressure system cut flux usage by half and keep the inside clean – a real daily saving for any heat wave soldering machine in busy THT production.
Third-party over-temperature protection works together with PLC+PID closed-loop control to stop problems before they start. Real-time monitoring and instant emergency stop keep operators and the whole pcb soldering machine safe during non-stop production.
Independent horizontal heating zones with closed hot-air path and rectifier plates give perfectly even heat from edge to edge. Warm-up takes only about 15 minutes and normal power stays at 7kW – the most efficient heating design among similar Wave Soldering Machine for PCBs.
| DIP Line Equipment List
| Model | W4 | W3 | W2 |
| Dimension:(mm) | 4200X1250X1500 | 3600X1250X1500 | 2900X1160X1500 |
| Weight(kg) | Approx.1500kg | Approx.1200kg | Approx.790kg |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 32kw | 24kw | 16kw |
| Operation Power | 12kw | 9kw | 7kw |
| Control System | PLC | ||
| Spray System | |||
| Transmission Method | Step motor | ||
| Spray Pressure | 0.25Mpa--0.4Mpa | ||
| lux flow | 10--100ml/min | ||
| Exhaust Diameter | Φ200mm | ||
| Exhaust Capacity | 25m3/min | ||
| Preheating System | |||
| Preheating Mode | Hot air | ||
| Control Mode | PID + SSR | ||
| Preheating Zone | 4 | 3 | 2 |
| Preheating Length | 1800mm | 1600mm | 1200mm |
| Preheating Temp. | (Room Temperature)-250°C | ||
| Warm-up Time(min) | Approx.15min (setting 150°C) | ||
| Conveyor System | |||
| PCB Size:LxW(mm) | Min:80x60mm; Max:400x300mm | ||
| Conveyor Speed | 0-2000(mm/min) | ||
| Conveyor Height | 750+/-20 (mm) | ||
| Finger | Double hook claw (Standard) | ||
| Conveyor width control | Manually | ||
| Conveyor Angle | 4~7degree | ||
| Soldering System | |||
| Solder Pot style | Mechanical Motor drive | ||
| Solder Pot Material | Full Titanium (Standard FT) | ||
| Solder pot temperature | 300°C | ||
| Solder pot capacity | Lead-free 350kg | Lead-free 300kg | Lead-free 250kg |
| Other | |||
| Finger cleaning system | Brush | ||
| DIP Line Equipment List
Our DIP production line offers advanced tools for efficient and precise PCB assembly. The fully automated DIP line includes a DIP insertion line for accurate component placement, a wave loader for smooth PCB entry, a wave unloader for safe exit, and an assembly belt line for final checks. This high-quality PCB DIP production line ensures stable operation, reliable THT insertion, and cost-effective assembly, meeting diverse industry needs. With modular designs and global support from I.C.T, it boosts productivity for through-hole tasks.
| Customer Success Video
I.C.T engineers went to Uruguay to install and commission the W-series Wave Soldering Machine for PCBs for a smart meter manufacturer. The customer runs a high-volume DIP production line and needed stable lead-free soldering for complex PCBs with large parts. After our team completed the setup and operator training, the machine reached full speed with only 7kW running power and perfect joint quality. The customer shared a video showing the Wave Soldering Machine for PCBs running smoothly in their THT assembly line, praising the low energy cost, easy maintenance and excellent after-sales support. This Uruguay smart meter project has become a successful reference for many Latin American DIP lines.
| Expert Services and Training
I.C.T supplies total support for every Wave Soldering Machine for PCBs – from factory layout planning and professional installation to complete operator training and 7×24 global technical help. Our skilled team makes sure your heat wave soldering machine and whole THT line run at top speed with zero worry.
| Customer Praise
Customers worldwide praise our Wave Soldering Machine for PCBs for its strong reliability, very low electricity bill and perfect soldering quality on difficult boards. They especially like the fast global response, solid export packaging and excellent performance among similar pcb soldering machine options.
| Quality Certifications
Every I.C.T Wave Soldering Machine for PCBs carries CE, CCC, UL, RoHS and ISO9001 certifications plus several invention patents, fully meeting the highest international safety and environmental standards for modern DIP production lines.
| About I.C.T Company and Factory
I.C.T is a professional one-stop solution provider for SMT and DIP production lines with over 25 years of experience. Our 12,000㎡ factory in Dongguan employs 89 staff including 20 engineers. We design and manufacture all core equipment in-house and serve over 1600 customers across 72 countries. Strict quality management and continuous innovation make us the most reliable partner for high-performance machine soldering pcb equipment worldwide.
