I.C.T-W2
I.C.T
| Quantity: | |
|---|---|
| Soldering Wave Machine PCB for Modern THT Lines
The I.C.T W-series Soldering Wave Machine PCB is a smart, space-saving Wave Solder Machine designed for medium-volume THT assembly lines and DIP production lines. This Mini Wave Soldering system uses Japanese Kuroda precision nozzle for tiny flux spots, fully independent horizontal heating for even temperature curves, and advanced energy-saving technology to run at just 7kW during normal production. Optional nitrogen protection makes it ideal for high-quality Lead-Free Wave Soldering on automotive electronics, smart meters and consumer products. Thousands of factories worldwide trust this compact Soldering Wave Machine PCB for its outstanding performance and easy integration.
| Feature
Japanese Kuroda nozzle with adjustable atomizing zone and pyramid filter produce tiny, uniform flux dots every time. Digital flow meter and stable pressure tank cut flux usage by up to 50% and keep the chamber spotless – a huge benefit for Mini Wave Soldering in busy THT lines.
Independent third-party over-temperature protection plus PLC+PID closed-loop system create multiple safety shields. Real-time monitoring and instant shutdown keep operators and the whole Soldering Wave Machine PCB safe during 24-hour Lead-Free Wave Soldering.
Fully independent horizontal heating zones with closed hot-air path and rectifier plates ensure absolutely even temperature on every board. Warm-up takes only about 15 minutes and normal power stays at 7kW – the smartest heating solution among similar Wave Solder Machine.
| DIP Line Equipment List
| Model | W4 | W3 | W2 |
| Dimension:(mm) | 4200X1250X1500 | 3600X1250X1500 | 2900X1160X1500 |
| Weight(kg) | Approx.1500kg | Approx.1200kg | Approx.790kg |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 32kw | 24kw | 16kw |
| Operation Power | 12kw | 9kw | 7kw |
| Control System | PLC | ||
| Spray System | |||
| Transmission Method | Step motor | ||
| Spray Pressure | 0.25Mpa--0.4Mpa | ||
| lux flow | 10--100ml/min | ||
| Exhaust Diameter | Φ200mm | ||
| Exhaust Capacity | 25m3/min | ||
| Preheating System | |||
| Preheating Mode | Hot air | ||
| Control Mode | PID + SSR | ||
| Preheating Zone | 4 | 3 | 2 |
| Preheating Length | 1800mm | 1600mm | 1200mm |
| Preheating Temp. | (Room Temperature)-250°C | ||
| Warm-up Time(min) | Approx.15min (setting 150°C) | ||
| Conveyor System | |||
| PCB Size:LxW(mm) | Min:80x60mm; Max:400x300mm | ||
| Conveyor Speed | 0-2000(mm/min) | ||
| Conveyor Height | 750+/-20 (mm) | ||
| Finger | Double hook claw (Standard) | ||
| Conveyor width control | Manually | ||
| Conveyor Angle | 4~7degree | ||
| Soldering System | |||
| Solder Pot style | Mechanical Motor drive | ||
| Solder Pot Material | Full Titanium (Standard FT) | ||
| Solder pot temperature | 300°C | ||
| Solder pot capacity | Lead-free 350kg | Lead-free 300kg | Lead-free 250kg |
| Other | |||
| Finger cleaning system | Brush | ||
| DIP Line Equipment List
Our DIP production line offers advanced tools for efficient and precise PCB assembly. The fully automated DIP line includes a DIP insertion line for accurate component placement, a wave loader for smooth PCB entry, a wave unloader for safe exit, and an assembly belt line for final checks. This high-quality PCB DIP production line ensures stable operation, reliable THT insertion, and cost-effective assembly, meeting diverse industry needs. With modular designs and global support from I.C.T, it boosts productivity for through-hole tasks.
| Customer Success Video
I.C.T engineers went to Uruguay to install and commission the W-series Soldering Wave Machine PCB for a smart meter manufacturer. The customer runs a high-volume DIP production line and needed stable lead-free soldering for complex PCBs with large parts. After our team completed the setup and operator training, the machine reached full speed with only 7kW running power and perfect joint quality. The customer shared a video showing the Soldering Wave Machine PCB running smoothly in their THT assembly line, praising the low energy cost, easy maintenance and excellent after-sales support. This Uruguay smart meter project has become a successful reference for many Latin American DIP lines.
| Expert Services and Training
I.C.T provides total support for every Soldering Wave Machine PCB – from factory layout design and professional installation to comprehensive operator training and 7×24 global technical service. Our experienced engineers guarantee your Mini Wave Soldering and entire THT line operate at peak efficiency with zero risk.
| Customer Praise
Factories around the world praise our Soldering Wave Machine PCB for its outstanding stability, extremely low electricity consumption and perfect soldering quality on complex boards. They especially love the fast global response, strong export packaging and unbeatable value among similar Lead-Free Wave Soldering systems.
| Quality Certifications
Every I.C.T Soldering Wave Machine PCB carries CE, CCC, UL, RoHS and ISO9001 certifications plus multiple invention patents, fully meeting the strictest international safety and environmental standards for modern DIP production lines.
| About I.C.T Company and Factory
I.C.T is a professional one-stop solution provider for SMT and DIP production lines with over 25 years of experience. Our 12,000㎡ factory in Dongguan employs 89 staff including 20 engineers. We design and manufacture all core equipment in-house and serve over 1600 customers across 72 countries. Strict quality management and continuous innovation make us the most reliable partner for high-performance Wave Solder Machine worldwide.
