SMT Fixture Cleaning Machine
| Quantity: | |
|---|---|
This advanced ultrasonic cleaning machine is designed specifically for cleaning SMT fixtures. It uses ultrasonic waves to penetrate and remove even the most stubborn residues, like solder paste and flux, ensuring that your fixtures are spotless and ready for the next phase of production. With a focus on efficiency, it helps to maintain the precision and longevity of your equipment, ensuring smooth, uninterrupted operations.
The machine uses ultrasonic technology to provide a thorough cleaning process that reaches deep into the fixtures, removing all contaminants effectively, ensuring high-quality production every time.
This cleaning system is built for speed, significantly reducing downtime between production runs. The quick cleaning time enhances the overall efficiency of your operation.
The machine is designed with sustainability in mind, using eco-friendly materials and processes. It meets all safety standards to ensure secure, reliable use in the factory environment.
| Specification:
| Specification | Details |
|---|---|
| Item | I.C.T-5200 |
| Cleaning Basket Size | Φ1000mm x H 200mm (Special size option) |
| Spray Unit | Upper/lower/front side, 720° all-around spray |
| 3-Level Filter System | 1mm / 50um / 20um filters |
| Clean Tank Capacity | 80L |
| Rinse Tank Capacity | 80L |
| Clean Spray Pressure | 5~6 kg/cm² |
| Clean Time | 5~15 Min |
| Rinse Time | 1~3 Min |
| Dry Time | 10~20 Min |
| Clean Detergent Heat Temp | Room temp~80°C |
| Rinse Water Heat Temp | Room temp~80°C |
| Hot Air Heat Temp | Room temp~90°C |
| Clean Pump Power | 2.2KW |
| Clean Detergent Power | 9KW |
| Hot Air Heat Power | 9KW |
| Air Blower Power | 4.0KW |
| Air Supply | 0.5*0.7MPa |
| Power Supply | 3 P, AC 380V, 50/60HZ, 33KW |
| Machine Size | L1380 x W2100 x H1400 (mm) |
| Machine Weight | 500KG |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice. If different, please follow the new list.
| SMT Line Equipment List
Our full SMT production line covers all the necessary equipment for the automated assembly process, from board loaders to reflow ovens. Every piece of equipment is engineered to work seamlessly with others, creating a highly efficient and effective production environment.
| Product Name | Purpose in SMT Line |
|---|---|
| SMD PCB assembly Line | Turnkey Ful-auto SMT assembly line |
| SMT magazine loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| SMT assembly machine | Mounts components onto PCBs precisely. |
| BGA reflow oven | Melts solder to form solid joints. |
| Customer Success Video
On April 11, 2026, I.C.T engineers traveled to Germany to provide on-site technical support for the installation of a fully automated SMT production line. This included the setup of the Electric Fixture Cleaning Machine. The engineers conducted comprehensive training for the customer's team, ensuring they were fully equipped to operate the entire SMT production line, including fixture cleaning, reflow ovens, and other crucial equipment. This support helped the customer achieve high-quality, efficient production from the very first run.
| Service and Training Support
I.C.T provides full installation and training services for our equipment. Our experienced engineers are dedicated to making sure that your team is fully equipped to operate the machinery efficiently. From on-site sessions to remote support, we ensure that you get the most out of your investment.
| What Our Customers Say
Customers have found that the I.C.T cleaning machine improves their operational efficiency and extends the life of their fixtures. With easy-to-use features and excellent after-sales support, customers can rely on the machine to maintain their production standards without interruption.
| Certifications and Standards
All I.C.T products are CE, RoHS, and ISO9001 certified, ensuring that they meet the highest standards of quality, safety, and environmental responsibility. Our commitment to quality is reflected in every product we deliver.
| About I.C.T Company and Factory
Since 2012, I.C.T has been a trusted partner in providing SMT, DIP, and coating solutions. With a team of over 20 engineers and a manufacturing facility of 12,000 square meters, we serve over 1,600 customers in 72 countries. Our factory follows stringent quality control processes to deliver reliable products that meet the evolving needs of the electronics industry.
