| I.C.T Acrab-Series Wave Soldering Machine Equipment
This wave soldering machine equipment has been feeding factories for over ten years. Three models: 350, 450, 615 mm. Dual spray, long preheat, steady wave, simple controls. Operating power 8-10 kW. Change parts in minutes. Customers in 72 countries keep ordering more because it simply works.
| Feature
The whole spray unit rolls out on rails. Two Japanese Kuroda nozzles sit there, stepper motors drive them dead accurate. Flux lands exactly where it should. Auto-clean cycle runs itself. 316 stainless steel laughs at acid. Push the drawer back in and the wave soldering machine equipment is ready for the next shift.
Three separate zones, total 1800 mm. Hot air plus infrared hit the board at once. Fifteen minutes to 250 ℃. Thick insulation keeps temperature within two degrees everywhere. Each zone pulls out like a file drawer. Swap a heater before the coffee gets cold. Top preheat option waits when you need it.
Chain never skips. Heavy-duty titanium double-hook fingers clamp 615 mm automotive boards like they mean it. Patented entry stops boards from falling. Speed holds ±2 mm/min. Fingers wash themselves during production. Width adjustment manual or electric. The conveyor never gives the wave soldering machine equipment an excuse to stop.
One-piece cast-iron pot with enamel coat, 500-700 kg capacity, zero deformation after years. Dual wave stays under 0.5 mm movement. Automatic dross channel pulls waste away. Joints come out bright and full. Tin consumption drops hard. That’s what real wave soldering machine equipment delivers.
High-power top fans start the instant boards clear the wave. Add bottom fans for thick multi-layer stuff. Temperature crashes fast. Components stay safe. Solder freezes shiny. Board comes out cool enough to grab. No thermal damage, no ugly joints. The wave soldering machine equipment finishes clean.
Big clear touch screen. PC+PLC runs everything. PID keeps temperature honest. Line slows, machine goes to sleep, saves tin and electricity. Full alarm history. Hand crank works when power dies. CE/UL certified. Any new operator learns it in one shift and trusts it the next day.
| DIP Line Equipment List
| Model | Acrab 350 | Acrab 450 |
| Dimension(mm) | 4420X1420X1750 | 4420X1520X1750 |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 33kw | 33kw |
| Operation Power | 8kw | 8kw |
| Control System | PC+PLC | PC+PLC |
| Preheating Zone | 3 | 3 |
| Preheating Length | 1800mm | 1800mm |
| Preheating Temp. | (Room Temperature)-250°C | (Room Temperature)-250°C |
| PCB Width(mm) | 50-350mm | 50-450mm |
| Finger | Spring Pressing Finger (Standard); Option:Spring Pressing Finger, Duck Mouth Finger | |
| Solder Pot Capacity | Lead-free 500kg | |
| Machine Weight(kg) | Approx.1600kg | Approx.1900kg |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| DIP Line Equipment List
Complete High Frequency Wave Soldering Machine Solution Insertion → loader → Acrab wave soldering machine equipment → unloader → inspection belt. Everything connects, everything talks. Boards flow fast and clean. Modular design grows with your orders. Global service keeps the whole line running near 100 % uptime.
| Product Name | Purpose in DIP Line |
|---|---|
| Automatic Insert Machine | Automatically places components onto PCBs with precision for DIP production line. |
Melts solder to form solid joints on PCBs during THT plug-in process. | |
Applies solder selectively to specific areas for accurate THT assembly | |
Inspects solder joints and placement defects on DIP assembled PCB. | |
Board input machine and board output machine | |
| DIP Peripheral | Peripheral products of DIP production line |
| Customer Success Video
Our engineers flew to Mexico with toolboxes. One automotive customer now runs two completely different boards on the same Acrab 350 wave soldering machine equipment — just swap fixtures. Zero bridges, perfect fillets. Same plant runs our coating line and SS-540 selective without drama. They made a video thanking us. We still play it when we need a smile.
| Expert Services and Training
We install, train your people, leave the line running perfect. Twenty engineers overseas. 24-hour online. Parts ship same day. Your team hits 99.5 % first-pass yield in days. Then we keep coming back until the wave soldering machine equipment feels like it’s always been yours.
| Customer Testimonials
“Packing is very safe and professional.” “Your engineers are patient and skilled; they solved all problems in two days.” “The wave soldering machine runs stably with almost no dross – real energy saving!” “Response speed is amazing; questions answered within one hour anytime.”
| Quality Certifications
CE, RoHS, ISO9001:2015, multiple patents. Every wave soldering machine equipment runs 72 hours full load in Dongguan before it ships.
| About I.C.T Company and Factory
Since 2012. Almost 90 people. 12,000 m² factory in Dongguan. We build the critical parts ourselves. Over 1,600 customers, 72 countries, eight overseas offices, twenty engineers ready to fly. We’re not going anywhere.
