High Quality Automatic SMT PCB Magazine Loader and Unloader
High quality PCB loader unloader, SMT magazine loader, mini cyclic Loader, mini size SMT loader, 90 degree SMT magazine loader, SMT Automatic Vacuum and Magazine Loader, NG/ OK unloader, for SMT SMD Production Line.
PCB Mini Size Loader
Modular design, optional assembly as per client's requipment.
Rugged steel design, improves equipment stability.
Top & Bottom pneumatic clamps to secure magazine rack.
Soft touch LED control panel or touch screen can be selected.
| Model（Loader) | LD-M | LD-L | LD-LL | LD-XL |
| Dimension(mm) | 1330*765*1250 | 1650*845*1250 | 1800*909*1250 | 1800*970*1250 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 | 50*50-530*460 |
| Rack Size(mm) | 355*320*563 | 460*400*563 | 535*460*563 | 535*530*563 |
| Control System | PLC | |||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | |||
| Weight | 160 Kg | 220 Kg | 280 Kg | 340 Kg |
| Model （Unloader) | UL-M | UL-L | UL-LL | UL-XL |
| Dimension(mm) | 1730*765*1250 | 2065*845*1250 | 2660*909*1250 | 2660*970*1250 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 | 50*50-530*460 |
| Rack Size(mm) | 355*320*563 | 460*400*563 | 535*460*563 | 535*530*563 |
| Control System | PLC | |||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | |||
| Weight | 180 Kg | 240 Kg | 300 Kg | 360 Kg |
