SMT PCB Loader Unloader
I.C.T
| Quantity: | |
|---|---|
| I.C.T Vacuum Loaders (VL Series)
I.C.T Vacuum Loaders (VL Series) are designed to streamline PCB handling in SMT production lines. Using advanced vacuum technology, these loaders provide precise and stable transport, ensuring minimal risk of damage during handling. The system adapts to a wide range of PCB sizes and thicknesses, and its automatic suction adjustment feature enhances flexibility for varying production needs. With an integrated SMEMA interface, the loaders seamlessly connect to other SMT equipment, ensuring an uninterrupted production process. Perfect for high-mix environments, these loaders are efficient, customizable, and built to last.
| Advanced Vacuum and Clamping Technology
The I.C.T Vacuum Loaders use high-precision vacuum control technology to ensure that each PCB is handled securely throughout the production process. This technology minimizes the risk of PCB damage and ensures smooth movement, maintaining consistent product quality and operational stability.
Our vacuum loaders feature automatic suction adjustment, which allows them to adapt to various PCB sizes and thicknesses. This flexibility ensures that the loader can handle a wide variety of PCB designs and production requirements, making it an essential tool for high-mix manufacturing environments.
I.C.T Vacuum Loaders operate at high speeds to optimize your production process. With quick cycle times, the loaders minimize downtime and improve overall efficiency, ensuring that your SMT line runs smoothly and at full capacity throughout the production day.
The loaders are equipped with a SMEMA interface, which ensures smooth integration with other SMT equipment such as pick-and-place machines, reflow ovens, and AOI systems. This seamless connectivity streamlines the entire production line and eliminates manual intervention, reducing the risk of errors and downtime.
The transport height of the I.C.T Vacuum Loaders is customizable, allowing it to be easily integrated into different production line configurations. Whether you have a compact workspace or a large production floor, these loaders can be adjusted to meet your specific needs.
| Specification
| Item | Translational Vacuum Loader | Vacuumand Magazine Loader | ||
|---|---|---|---|---|
| Model | VL330 | VL460 | VL1200 | VM330 |
| Dimension (mm) | 600 × 1002 × 1300 | 800 × 1270 × 1300 | 1450 × 1200 × 1300 | 650 × 1050 × 1300 |
| PCB Size (mm) | 50 × 50 ~ 450 × 330 | 50 × 50 ~ 530 × 460 | 50 × 50 ~ 1200 × 350 (customizable) | 50 × 50 ~ 450 × 330 |
| PCB Capacity | 400 pcs (0.6mm thick) | 400 pcs (0.6mm thick) | 100 pcs (0.6mm thick) | 400 pcs (0.6mm thick) |
| Cycle Time | Approx. 12 seconds or specify | Approx. 12 seconds or specify | Approx. 15 seconds or specify | Approx. 12 seconds or specify |
| Control System | PLC | PLC | PLC | PLC |
| Power | Max 150 VA | Max 150 VA | Max 150 VA | Max 150 VA |
| Air Supply | 4–6 bar, 10 L/min | 4–6 bar, 10 L/min | 4–6 bar, 10 L/min | 4–6 bar, 10 L/min |
| Transport Height | 900 ± 20 mm (customizable) | 900 ± 20 mm (customizable) | 900 ± 20 mm (customizable) | 900 ± 20 mm (customizable) |
| PCB Direction | Left to Right or Right to Left | Left to Right or Right to Left | Left to Right or Right to Left | Left to Right or Right to Left |
| Communication | SMEMA (In & Out) | SMEMA (In & Out) | SMEMA (In & Out) | SMEMA (In & Out) |
| Power Supply | 1 Phase AC 220V 50/60Hz (Option: 110V–380V) | 1 Phase AC 220V 50/60Hz (Option: 110V–380V) | 1 Phase AC 220V 50/60Hz (Option: 110V–380V) | 1 Phase AC 220V 50/60Hz (Option: 110V–380V) |
| Weight | 130 kg | 150 kg | 380 kg | 120 kg |
| Option | Automatic width adjustment | Automatic width adjustment | Automatic width adjustment | Automatic width adjustment |
| Related SMT Equipment
To build a complete turnkey SMT production line, I.C.T offers a full range of compatible machines. Our solutions include automatic printers, high-speed pick-and-place machines, reflow ovens, AOI systems, conveyors, depanelizers, and PCB unloading machines. All equipment is designed to work together smoothly, helping customers create efficient, space-saving layouts such as U-shaped lines that fit tight factory floors while maintaining high output.
| Successful Customer Project in Saudi Arabia
In September 2025, I.C.T engineers traveled to Saudi Arabia for an installation and training service at a customer’s factory.
The customer, a manufacturer of home LED lighting, required a fully automated SMT production line. We provided a solution consisting of 13 machines, with a total length of about 29 meters. However, the customer’s available space was only 21 meters long and 5 meters wide. We designed a U-shaped layout for the production line, which was installed in a 16-meter-long, 2.7-meter-wide space, meeting the customer’s requirements. After 2 days of installation and 6 days of training and technical support, our engineers successfully completed the handover.
| Professional Service and Training
I.C.T offers comprehensive after-sales services and technical support to ensure the smooth operation of your SMT production line. Our services include:
Equipment Installation and Debugging: Our engineers will handle the installation and debugging of the equipment on-site to ensure optimal performance.
Training: We provide in-depth training on both machine operation and maintenance, ensuring your team can fully utilize the equipment.
Remote Technical Support: Our team is available 24/7 for remote technical assistance, ready to solve any issues you encounter.
Regular Maintenance and Service: We offer scheduled maintenance services to keep your equipment running at peak performance.
| What Our Customers Say
“Working with I.C.T was a seamless experience. The installation and commissioning of the equipment were efficient, and the technical support team was very professional. The fully automated SMT line has greatly improved our production efficiency and reduced downtime.” — LED Lighting Manufacturer, Saudi Arabia
“The precision and stability of the Vacuum Loader were key factors in our decision to choose I.C.T. It perfectly meets our needs and has performed exceptionally well in our production process.” — Consumer Electronics Manufacturer
| Quality Certifications
I.C.T’s equipment has been certified with multiple international standards, including:
CE Certification
ISO 9001 Quality Management System
RoHS Compliance
UL Certification
These certifications ensure our products meet global standards, giving you peace of mind when using our equipment.
| About I.C.T – Your Reliable SMT Partner
I.C.T is a leading manufacturer of SMT equipment, providing comprehensive solutions for electronic manufacturing, including pick-and-place machines, reflow ovens, automatic printers, and vacuum loaders. Our products are widely used in industries such as consumer electronics, LED lighting, automotive, and more.
With a strong R&D team and state-of-the-art manufacturing capabilities, I.C.T is committed to producing high-performance, reliable equipment. All of our machines are built using top-tier components to ensure durability and long-term functionality. We also offer extensive global customer support, including on-site installation, training, and 24/7 technical assistance.
