| I.C.T Coating Spraying Gluing Machine for PCB
The I.C.T coating spraying gluing machine for PCB leads in easy and quick board work. It has simple program setup and fast change times for good results. This PCB board coating machine handles sizes from 50x50 to 450x460mm. It moves X=450mm, Y=450mm, Z=100mm. Users make any spray path, and the screen shows it clear. Tracks mirror, array, or copy for many boards. It counts data like output and time auto. The coating spraying gluing machine for PCB fits drive power, industrial control, LED, automotive, communication, and more. It meets wide needs with high speed and clean shop air.
| Feature
Transmission System
The transmission system builds on a high-strength platform for steady runs in the coating spraying gluing machine for PCB. Imported servo motors and drivers give smooth power. Servo with slide rail ensures exact X/Y/Z repeat. Dust cover keeps screw and rail clean to cut maintenance. Tank chains hold pipes and lines neat. This setup lowers faults and supports long work hours.
Transport System
The transport system uses unique chains to stop PCB jams in the coating spraying gluing machine for PCB. Motor sets speed and stops sharp. Cylinder clamps hold boards firm. Rail width changes semi-auto for easy flow. Chains and profiles take heavy loads without bend. It keeps smooth line in PCB board coating machine.
Coating System
The control system sets parts in order with standard labels for quick checks in the coating spraying gluing machine for PCB. High-precision servo runs stable. Heat design cools with air flow. PC and board control adds trust. It links easy to full lines.
Control System
The operator system makes new programs in under 10 minutes and changes in less than 2 on Windows 10. Friendly software teaches and shows paths live. CCD vision adds as option. Platform adjusts for all users. This eases daily use of the coating spraying gluing machine for PCB.
Operator System
General features include air curtains at track ends to block gas and keep shop clean. Programming edits any path with simple interface. Tracks mirror or copy for multi-boards fast. Auto count shows output and time. This aids quick setup in the PCB board coating machine.
Advanced Dual Valve Coating System
The valve system in the coating spraying gluing machine for PCB has dual design for complex jobs. Modular swap takes under 2 minutes for different valves. H-808 does fine dots for small parts in LED and gadgets. H-818 fans wide films for car boards. H-828 flows high for thick layers in power units. Optional U-axis turns 360° and tilts 45° to reach under parts. UV lamp checks live, CCD aims ±0.05mm. It cuts waste 20-30% and gives even IP67 guard.
| Specification
| Selective Conformal Coating Machines | ||||
| Model | I.C.T-T550 | I.C.T-T550U | I.C.T-T600 | I.C.T-T650 |
| Number of valves | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 1 head, precision valve 1 head) | 2 (atomization valve 2 head) | 4 (atomization valve 2 head, precision valve 2 head) |
| Control method | PC + Motion Control Card | |||
| Number of spindles | X, Y, Z | X, Y, Z,U | X, Y, Z | X, Y, Z |
| PCB size | 50*50~450*460mm | |||
| Spindle drive | Imported servo motor+ball screw module | |||
| Automatic cleaning of valves | with 5L Pressure Tank | |||
| Power supply | AC 220V±10%, 50/60HZ, 2.2KW | |||
| Dimension | L910*W1600*H1700mm | |||
| Net weight | 1000KG | |||
| Coating Line Equipment List
Our PCBA Coating Line offers advanced tools for efficient and precise circuit board protection. The fully automated coating line includes a selective coating machine for accurate application, a curing oven for durable finishes, AOI for quality checks, a lift and flipper for smooth handling, and a conveyor system for seamless production.
This high-quality PCBA Coating Line ensures stable operation, reliable dustproof, waterproof, and explosion-proof coating, meeting diverse industry needs. With modular designs and global support from I.C.T, it enhances productivity for protective coating tasks.
| Product Name | Purpose in PCBA Coating Line |
|---|---|
Applies precise protective coatings to circuit boards for dustproof, waterproof, and explosion-proof protection. | |
Hardens coatings with IR or UV light, ensuring durable and strong protection. | |
Transports circuit boards smoothly through the coating line for efficient processing. | |
Provides and stores PCB for the production line, ensuring smooth input and output. | |
| Conformal coating AOI | Inspects coating quality and detects defects to ensure high standards. |
| Customer Success Video
In the video "The European Journey of I.C.T Engineer - SMT Solution for Automotive Electronics," our engineer travels to a leading European client specializing in car dashboards. They purchased a complete PCBA coating line featuring the coating spraying gluing machine for PCB, along with PCB loader, UV curing oven, and unloader. Additional equipment includes selective wave soldering and AOI inspection with magazine buffer and NG/OK unloader. The engineer performs full installation and debugging to ensure optimal operation. He conducts thorough operational training covering basics, maintenance, and troubleshooting. During trial production, he collaborates to resolve challenges, optimize processes, and improve efficiency/quality. This support enables smooth, high-yield startup. The footage highlights precise selective coating on complex boards, fast programming, and seamless integration in automotive lines using the PCB board coating machine.
| Services and Training
I.C.T offers end-to-end installation, debugging, and maintenance for the coating spraying gluing machine for PCB. Our experienced engineers provide on-site or remote training on programming, daily operation, cleaning, and common fixes. We respond rapidly to queries via phone, email, or video, often resolving issues within hours. Comprehensive manuals and video guides supplement hands-on sessions. Spare parts are stocked globally for quick delivery. Regular follow-ups include process optimization and upgrades to match evolving needs. This builds operator confidence and minimizes downtime. In automotive or LED applications with the PCB board coating machine, we tailor support to specific coatings and board types. Clients gain long-term partnership for zero-risk expansion.
| What Clients Say
Customers highly praise our engineers for professional expertise, swift on-site resolutions, and patient training during European visits. They commend the coating spraying gluing machine for PCB for delivering uniform, defect-free layers even on intricate automotive boards. Secure, damage-proof packing ensures safe international shipping every time. Rapid response teams address questions in under 24 hours, preventing production halts. The machine's reliability and easy valve swaps boost output by 20-30% in high-mix lines. Many highlight how it exceeds expectations in durability and precision for the PCB board coating machine. Overall, it's trusted for enhancing product lifespan and compliance.
| Certifications and Standards
I.C.T proudly holds CE for safety, RoHS for environmental compliance, and ISO9001 for quality management. We possess multiple patents on innovative features like modular valves and path editing. Every coating spraying gluing machine for PCB undergoes rigorous in-house testing, including stability runs, accuracy checks, and material compatibility. Strict factory protocols cover component sourcing, assembly, and final inspection. This guarantees reliable, green operation in global markets. Certificates validate our commitment to excellence in the PCB board coating machine sector.
| About I.C.T Company and Factory
I.C.T operates self-owned R&D and production facilities spanning 12,000m² with 89 dedicated staff, including 20 engineers. Established in 2012 with $30 million registered funds and 8 branch offices, we've expanded rapidly. Serving over 1,600 customers across 72 countries, we provide one-stop SMT solutions from demand analysis to optimization. Factories enforce stringent quality management systems, precise detection processes, and full traceability. We cover semiconductors, PCBA, SMT, DIP, coating, robots, and assembly. Globalization and localization drive our cross-value platform in electronics manufacturing.
