| Smart PCB Destacker Conveyor
The I.C.T PCB Destacker Conveyor is the most reliable automated SMT conveyor at the beginning of PCB assembly line. It smoothly takes a full magazine of bare boards, separates the bottom one without scratching, and feeds it perfectly into the printer or next station. Aviation-grade aluminum frame, high-precision pusher and Industry 4.0 PLC guarantee zero damage and zero stoppage 24/7. One-button width sync and full CE protection make every PCB Destacker Conveyor the first choice for high-volume, high-quality electronics factories worldwide.
| Complete Conveyor Family Including Intelligent Destacker Models
I.C.T offers more than ten conveyor types so every line starts perfectly. Standard linking conveyors simply move boards. Inspection and cooling stations handle quality. The flagship PCB Destacker Conveyor comes in single-magazine, dual-magazine or ultra-high-speed servo versions with optional board warping detection and flip function. Heavy-duty chain and buffering models are also available. Every Conveyor Pcb Assembly Line can be fully customized in magazine size, speed and smart functions to match your exact production volume and board type.
| Detailed Product Features
High-precision vacuum suction + servo pusher separate even the thinnest 0.4 mm boards without bending or scratching. Adjustable separation force and speed protect warped boards perfectly. All mechanical parts meet strict ISO and CE standards, giving the PCB Destacker Conveyor zero damage rate after millions of cycles.
Standard 400 mm magazine holds up to 300 pcs. Automatic magazine change and empty alarm keep the line running without operator intervention. Bright tower lights show magazine status from far away. Anti-static design protects sensitive PCBs during the entire destacking process.
7-inch full-color touch screen plus reliable PLC makes setup extremely fast — change board thickness or speed in seconds. Optional Industry 4.0 module supports Hermes, CFX and all major MES systems. Software updates and remote diagnostics are free for life.
3 mm ESD flat belt runs whisper-quiet and clean. Stainless-steel chain option handles heavier boards perfectly. Both systems work flawlessly with the PCB Destacker Conveyor’s gentle push-out motion and never cause board jams.
| Reflow Oven Specification
| Parameter | Specification |
|---|---|
| PCB Width | 50–400 mm (500 mm optional) |
| Conveyor Height | 900 ± 20 mm |
| Transfer Speed | 0.5–20 m/min adjustable |
| Power Supply | AC 220 V 50/60 Hz |
| Power Consumption | 50–150 W |
| Direction | Left to Right (Right to Left optional) |
| Belt Material | 3 mm ESD flat belt or chain |
| Control Mode | PLC + Touch Screen |
| One-button Width Adjust | Optional (whole line sync) |
| CE Safety Standard | Full cover + sensor protection |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
Our High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Customer Success Story
Two senior I.C.T engineers flew to Uruguay to launch a complete high-speed line for a leading smart electric-meter manufacturer. The package included multiple PCB Destacker Conveyors, printers 471 & 481, Lyra622 mounter, AOI, reflow oven W2 and roller lines. Within seven days our team finished installation, magazine calibration and full operator training. The line now starts automatically every morning with zero manual board loading, and daily output has increased 35% while board damage dropped to zero.
| Professional Training & Support
From line layout design to daily mass production, I.C.T stands with you every step. We offer free online and on-site training, lifetime free software upgrades, and 7×24 remote support. When needed, our engineers arrive within 48 hours anywhere in the world. Spare parts ship same-day from eight global warehouses — your production never stops.
| Customer Praise
“The PCB Destacker Conveyor completely eliminated manual board loading — operators love it!” “Wooden crates were super strong — machines arrived perfect after ocean shipping.” “Engineers trained every shift until the destacker ran flawlessly.” “Support answers in minutes, even on weekends!” “Best line starter we’ve ever installed.”
| Our Certification
Every I.C.T machine carries CE, RoHS and ISO9001 certificates plus dozens of invention patents. Each PCB Destacker Conveyor passes a strict 48-hour full-load aging test before delivery. Quality is built in every single day — that’s why customers trust us year after year.
| About Us and Factory
Founded in 2012 in Dongguan, China, I.C.T has grown rapidly into a leading global SMT solution provider with nearly 90 passionate employees and a modern 12,000 m² factory. We design and manufacture all core components in-house under strict quality systems. More than 1,600 customers from 72 countries run our equipment every day. With eight overseas offices and continuous fast growth, I.C.T keeps delivering reliable PCB Destacker Conveyor and world-class service to electronics manufacturers worldwide.
