| Compact SMT mini PCB loader Unloader Stacking
In SMT production lines, every station must handle boards with care and consistency. The SMT mini PCB loader Unloader Stacking combines loading and unloading functions in a compact unit, feeding small PCBs from magazines at the start and stacking them safely at the end. Its mini design fits tight production areas while the stacking mechanism keeps boards moving without interruption. Advanced sensors monitor each transfer and send accurate signals to the control system. Industry 4.0 compatibility allows easy integration with printers, mounters, and reflow ovens. Factories value this machine because it reduces operator workload and protects delicate small boards from damage. Built with upgraded hardware that meets CE and ISO standards, it delivers reliable service through long shifts and changing production requirements.
| Detailed Product Features
The mini stacking system uses reinforced aluminum rails for smooth magazine movement. A heavier base keeps the unit steady even during continuous operation. Stainless steel screws enable quick and accurate width adjustment. Ergonomic access points make daily checks fast and safe. The entire structure complies with international quality standards and supports years of dependable use.
Electrical components transmit clear signals for precise board handling. Bright status indicators remain visible from any angle on the factory floor. High-frequency buttons respond immediately. Variable speed control allows perfect matching with the production line. The system operates quietly and stays cool throughout every shift.
The control platform supports IPC-CFX, Hermes, and SEMI SMT-ELS protocols. Upgrades can be completed quickly when needs change. Production data records automatically for later review. Operators adjust settings through a straightforward interface without stopping the line. The system remains flexible for future expansion.
LED inspection lights, metal chain conveyors, auto-width adjustment, and ionizer fans are available. Segment transport control handles special requirements. Every added feature arrives fully tested. These options allow the SMT mini PCB loader Unloader Stacking to integrate perfectly into any SMT layout.
| Specification
| Parameter | Specification |
|---|---|
| PCB Width | 50–400 mm (500 mm optional) |
| Conveyor Height | 900 ± 20 mm |
| Transfer Speed | 0.5–20 m/min adjustable |
| Power Supply | AC 220 V 50/60 Hz |
| Power Consumption | 50–150 W |
| Direction | Left to Right (Right to Left optional) |
| Belt Material | 3 mm ESD flat belt or chain |
| Control Mode | PLC + Touch Screen |
| One-button Width Adjust | Optional (whole line sync) |
| CE Safety Standard | Full cover + sensor protection |
