| Automatic PCB Turn Conveyor for SMT Lines
The PCB Turn Conveyor is a key element in SMT production lines, enabling precise 90-degree rotation and transfer of PCBs. Designed for smooth and stable operation, it connects upstream and downstream equipment, ensuring continuous workflow. Adjustable width and pitch settings allow it to accommodate various PCB sizes. Its durable construction and low-maintenance design make it a reliable solution for high-volume SMT production environments, streamlining operations and reducing the risk of misalignment or damage.
| Detailed Product Features
a. Automatic 90-Degree PCB Rotation
The PCB Turn Conveyor allows boards to rotate automatically, changing direction without manual intervention. This capability improves production flexibility, enabling seamless connection between machines in tight layouts. By ensuring precise turns, the conveyor reduces misalignment issues and helps maintain the quality and efficiency of your SMT line.
b. Smooth and Stable Transfer
Designed with a robust frame and precise motion control, the conveyor moves PCBs smoothly between machines. The stable operation reduces vibration and mechanical stress on boards, protecting delicate components during transfer. This ensures higher reliability and fewer production interruptions.
c. Adjustable for Various PCB Sizes
Width and pitch adjustments allow the conveyor to handle multiple PCB sizes. Quick adjustments reduce changeover time and improve line versatility, accommodating different products without requiring multiple conveyors or extensive reconfiguration.
d. Durable, Low-Maintenance Construction
Built for long-term, high-volume operation, the conveyor features wear-resistant components and a robust aluminum frame. Minimal maintenance is required, allowing continuous production with reduced downtime. Its reliability ensures it remains an integral part of the production line for years.
LED inspection lights, metal chain conveyors, and ionizer fans stand ready. Automatic width motors and segment transport control handle special requirements. Every option arrives fully tested. These choices let the smt mini pcb magazine loader match any SMT layout precisely.
| Specification
| Specification | Model TC350 | Model TC460 |
|---|---|---|
| Dimension (mm) | 7007301200 | 8008001200 |
| PCB Size (mm) | 5050400*350 | 5050530*460 |
| Cycle Time | Approx. 15 Seconds | Approx. 15 Seconds |
| Belt Type | Round Belt or Oblate Belt | Round Belt or Oblate Belt |
| Control System | PLC | PLC |
| Power | Max 250 VA | Max 250 VA |
| Transport Height | 900±20mm (or Customer Specified) | 900±20mm (or Customer Specified) |
| PCB Direction | L to R or R to L | L to R or R to L |
| Communication | SMEMA for Both In & Out | SMEMA for Both In & Out |
| Power Supply | 1 PH AC 220V 50/60Hz (Option: 110V to 380V) | 1 PH AC 220V 50/60Hz (Option: 110V to 380V) |
| Weight | 170 Kg | 220 Kg |
| Option | Automatic width adjustment | Automatic width adjustment |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
