English
| Parameter | Specification |
|---|---|
| Model | I.C.T-100A |
| PCB Size | 280 × 300 mm (Special size optional) |
| PCB Thickness | 0.3 ~ 4.0 mm |
| PCB Support Mode | Multifunctional fixture, Special fixture |
| X/Y Cutting Speed | 0 ~ 100 mm/s |
| Repeat Precision | ± 0.01 mm |
| Cut Precision | ± 0.1 mm |
| X/Y/Z Driving Method | Step Motor |
| Operation | Teaching Box |
| Spindle Speed | Max 40,000 rpm |
| Router Voltage | 220V, 50/60 Hz |
| Power Supply | 1.0 kW |
| Dimension (L×W×H) | 560 × 600 × 650 mm |
| Weight (with Vacuum Cleaner) | 85 kg |
| Dust Collection Method | Vacuum Cleaning |
| Vacuum Cleaner Air Volume | 12 ~ 20 m³/min |
| Vacuum Cleaner Dimension | 730 × 600 × 1450 mm |
| Vacuum Cleaner Voltage | 380V, 50/60 Hz, 1.2 kW |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
I.C.T offers comprehensive SMT production line solutions designed to support the entire electronics manufacturing journey. Our integrated systems combine board loading, solder paste printing, high-speed pick and place, SPI/AOI inspection, reflow ovens, and flexible depaneling options including the Panel Separator Router for Cutting PCB. We work closely with customers from initial factory layout planning through equipment selection, professional installation, operator training, and long-term process optimization. This complete approach enables manufacturers in smartphone, automotive, medical, and consumer electronics industries to build efficient, scalable, and high-quality production lines that meet today’s demanding market requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| SMD PCB assembly Line | Turnkey Ful-auto SMT assembly line |
| SMT magazine loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| SMT assembly machine | Mounts components onto PCBs precisely. |
| BGA reflow oven | Melts solder to form solid joints. |
| Customer Success Video
Successful On-Site Installation in Portugal
In April 2026, I.C.T sent a professional engineer to Portugal to perform complete on-site installation and comprehensive training for a full SMT production line focused on automotive electronics, specifically car lighting and control systems. The customer was very satisfied with the entire project. They particularly appreciated the smooth installation process and the clear, practical training sessions that helped their team quickly gain confidence in operating the complete line. This successful collaboration further strengthened the customer’s trust in our full-factory solution capabilities.
| Service and Training Support
I.C.T provides complete service and training support for full SMT factory solutions. From initial factory planning and line design to equipment installation, operator training, process optimization, and ongoing technical assistance, our experienced engineers are committed to customer success. We offer both on-site and remote support to help solve problems quickly and improve production efficiency continuously. By building long-term partnerships, we help manufacturers reduce operational risks, maintain high quality standards, and achieve sustainable growth in competitive global electronics markets.
| What Our Customers Say
Our customers consistently speak highly of I.C.T’s professional service. They often praise the expertise and quick response of our engineers, the reliable performance and sturdy build quality of our equipment, and the careful packaging that ensures machines arrive in perfect condition. Many clients have also highlighted our fast and effective technical support whenever questions or issues arise. Overall, they express strong satisfaction with the results achieved after integrating our desktop and inline routing solutions into their production lines.
| Certifications and Standards
I.C.T equipment fully complies with rigorous international standards, including CE for safety, RoHS for environmental protection, and ISO9001 for quality management systems. We also hold multiple patents covering advanced technologies in routing and dust collection systems. These certifications demonstrate our strong commitment to delivering safe, reliable, high-performance solutions that customers can trust in demanding electronics manufacturing environments worldwide.
| About I.C.T Company and Factory
I.C.T operates its own research and development center, modern manufacturing facilities, and strict quality management systems. With more than 25 years of accumulated experience in the electronics industry and continuous rapid growth, we have successfully supported over 1,600 customers across 72 countries. Our dedicated team of engineers provides complete SMT factory solutions, from initial consultation and planning to equipment supply, installation, training, and long-term technical support. We are committed to being a reliable long-term partner for manufacturers seeking efficient and high-quality production lines.
