| High-Precision PCBA / IC Placement Machine
Engineers placed the PCBA / IC Placement Machine at the final station of online laser cutting solutions used in semiconductor manufacturing. It takes separated PCBA boards from the cutter, scans each one with CCD vision, and uses six nozzles to place good boards into trays while directing NG boards to a separate bin. The machine runs at 1800-2000 pieces per hour and meets strict anti-static requirements that semiconductor and automotive customers demand. PC control and a clear screen let operators watch every move. Automatic tray supply and stacking keep the line moving steadily with almost no manual work needed.
| Detailed Product Features
Instant CCD Inspection
Boards arrive and CCD immediately checks size while reading QR codes. The system separates good parts from NG ones before placement begins. This early check protects quality and prevents defective boards from reaching customer trays.
Six-Nozzle Multi-Axis Handling
Six nozzles move under precise multi-axis control and adjust distance automatically from 10 mm to 35 mm. Each board is lifted and placed gently so delicate semiconductor components stay safe throughout the cycle.
Automatic Tray Management
Empty trays lift into position while full trays stack neatly on the opposite side. Sensors count every tray and signal when AGV pickup is ready. The steady motion keeps the line running without pauses or manual handling.
Smooth Equipment Communication
Standard links connect the PCBA / IC Placement Machine directly to the laser cutter and upstream loader. Operators see the full process on the PC screen and adjust settings quickly when production needs change.
Complete Semiconductor Online Laser Cutting Solution
The PCBA / IC Placement Machine serves as the final station in a complete laser depaneling solution. It connects perfectly with the Automatic Semiconductor PCB Loader at the front and the PCBA Online Laser Cutting Machine in the middle. Together these three machines form one efficient line that handles feeding, cutting, inspection, and final placement with no manual steps in between.
| Specification
| Parameter | Specification |
|---|---|
| Model | I.C.T-PP3025 |
| PCB Size | 300×250 mm |
| Board Size Check & Code Scan | CCD |
| Nozzle | 6 pcs |
| Automatic Tray | With empty trays and storage trays |
| Tray Number | 18×8 pcs & 19×7 pcs |
| Capacity | 1800-2000 pcs/h |
| Control Method | PC |
| Direction | Left to Right |
| Dimension | 1700×1350×1800 mm |
| Weight | 1500 kg |
I.C.T keeps working on quality and performance. Specifications and appearance may be updated without prior notice.
| SMT Line Equipment List
Turnkey means bare board in, finished panel out, no babysitting. The PCB Unloader Loader feeds clean at the front, catches clean at the back. Printer hits perfect paste. Placer drops every component dead-center. Reflow solders solid. AOI checks everything. All stations stay locked in sync. Labor stays thin. First-pass yield stays north of 99.5 %. Uptime stays brutal. Automotive, medical, consumer, LED—standards crushed, costs crushed.
| Customer Success Story - Successful Delivery in Malaysia
I.C.T delivered a full laser depaneling line to a semiconductor customer in Malaysia. Our engineers traveled on site, installed the complete system including the loader, laser cutter, and PCBA / IC Placement Machine, then tuned every parameter and trained the customer’s team. The line now runs with steady output and excellent quality. The customer reports smooth daily operation and quick help whenever needed.
| Professional Service and Training
Complete Factory Support
I.C.T provides full on-site installation, testing, and operator training for every complete production system. Our engineers remain at the factory until the entire semiconductor line reaches full speed and quality targets. We continue to supply spare parts, remote diagnostics, and technical assistance long after the project ends. From initial planning meetings through years of daily operation, we support customers at every stage so they can focus on growth instead of equipment worries. More than 1,600 factories in 72 countries have relied on our complete solutions to build and maintain efficient manufacturing lines.
| Customer Feedback-What Customers Say
Semiconductor factories worldwide appreciate the PCBA / IC Placement Machine for its consistent daily performance and straightforward daily use. Customers frequently mention that our engineers arrive well prepared, resolve issues promptly, and explain every detail clearly during training sessions. They also speak highly of the secure packaging that protects machines during long-distance transport and the rapid responses we provide when questions arise. Many note that the full line performs exactly as expected and helps them meet demanding production schedules without difficulty.
| Our Quality & Certificates
Every PCBA / IC Placement Machine carries CE, RoHS, and ISO9001 certifications along with patents covering its scanning and placement technology. These official documents confirm that the equipment satisfies international safety, environmental, and quality requirements. Factories can install the machine with complete confidence because it follows the same high standards that I.C.T applies across every full-line solution delivered to customers around the world.
| About Us and Factory
Your Full-Solution Manufacturing Partner
I.C.T maintains its own R&D center and modern production factory in Dongguan, China. Our team of 89 people includes 20 experienced engineers who design and build complete lines for semiconductor and electronics manufacturers. We have expanded steadily while serving more than 1,600 customers across 72 countries. Every machine undergoes thorough testing before shipment. From the earliest plant layout discussions to ongoing process improvements, we help customers establish efficient lines and keep them operating at peak performance for many years. Our global service network ensures that every project succeeds and continues to deliver value.
