| Automatic Refurbished SMD Mounter
The Yamaha YC8 is a fully automatic, pre-owned SMD pick and place machine designed for efficient PCB assembly. Featuring multi-head placement and dual-beam handling, the YC8 offers flexible setup, high-speed production, and reliable operation. Integrated vision and feeder systems ensure accuracy while reducing operator intervention, making it ideal for mid-to-large scale electronics manufacturing.
| Product Features
High-Speed Multi-Head Placement
Equipped with multiple heads, the YC8 achieves consistent placement accuracy for 0101 to 0315 components. Dual-lane support allows simultaneous handling of small and large PCBs.
Integrated Vision System
Side-view and top-view cameras verify component alignment in real time. On-the-fly scanning reduces misplacement errors and ensures high-quality PCB assembly.
Optimized Feeder Management
The auto-loading feeder system and tray sequencer reduce production interruptions and eliminate downtime during feeder replacement, supporting continuous high-efficiency operation.
| Specification
| Model | YSM20R - Z:LEX |
| Applicable PCB | Single lane L810 x W490 to L50 x W50 Dual stage Note: For X-axis 2-beam option only 1PCB conveyance: L810 x W490 to L50 x W50 2PCB conveyance: L380 x W490 to L50 x W50 |
| Mounting capability | X-axis 2-beam: High-speed multi-purpose (HM: High-speed Multi) head x 2 95,000CPH (under optimum conditions as defined by Yamaha Motor) |
| Mounting accuracy | ±0.035mm (±0.025mm) Cpk≧1.0 (3σ) (under optimum conditions as defined by Yamaha Motor when standard evaluation materials are used) |
| Applicable components | High-Speed Multi (HM) Head NOTE: 0201 to W55 x L100mm (Indexing recognition exceeding W45mm), height 15mm or less Note: Component height of 6.5mm or higher or components sizes of 12mm in in length/width or greater requires optional multi camera. Please contact us for info regarding mounting 0201 components. Odd-shaped components (FM: Flexible Multi) head: 03015 to W55 x L100mm (indexing recognitions exceeding W45mm), Height 28mm or less |
| Number of component types | Fixed plate: 140 types (conversion for 8mm tape feeder) Feeder carriage exchange: Max 128 types (conversion for 8mm tape feeder) Trays for 30 types (Fixed type: maximum, when fitted with sATS30) and 10 types (Carriage type: maximum, when fitted with cATS10) |
| Power supply | 3-phase AC 200/208/220/240/380/400/416 V ±10 % 50/60Hz |
| Air supply source | Clean dry air of 0.45 MPa or more |
| External dimension | L1,374 x W1,857 x H1,445mm |
| Weight | Approx. 2,050kg |
* Specifications and appearance are subject to change without prior notice.
* Contact I.C.T for more details.
