| Reliable PCB SMT Printing Automatic Machine for Growing Production
High-Precision SMT Printing StepThe PCB SMT Printing Automatic Machine begins medium SMT lines with Taiwan TBI linear guide-ways and SANYO stepper motor for rock-solid motion. Blade pressure and printing speed is adjustable, precision pressure gauge and speed controller display give instant control. Suspension squeegee system makes printing more even. Modular universal bench with alignment device for PCB board and frame fits single or double sided boards. Stencil frame arms can be adjusted for different size ranges from 370470mm to 1050650mm. Auto printing; stable and efficient printing quality. Under 10-second cycle lets the stencil printer solder paste high precision handle phone, router or medical device SMT lines smoothly.
| Feature
The pin and support block shall be suitable for different one-sided and double-sided PCB, and the pin of different size shall be suitable for different PCB holes. Operation simple, the positioning is accurate, and the fixed position is flexible and adjustable. Imported stepper motor Taiwan precision guide rail ensures stability, squeegee system can be lifted by manual conversion to add solder paste and cleaning operation, limit sensor flexible adjustment to reduce transportation travel. This keeps boards 0.2-6mm thick locked tight in PCB assembly lines so smt printing stays perfect for placers.
Direct connection squeegee structure. The squeegee is independently controlled by two high-precision cylinder to ensure accurate and stable pressure. The double slide positioning rails ensure the accuracy and stability of the squeegee. Touch screen operation. Friendly English MMI interface, teaching and navigation function. Operation mode: manual, semi-automatic and full-automatic. The core control parts adopt imported high-quality brands to ensure the stability and operability of the printer. Auto printing, stable and efficient printing quality. This delivers stencil printer solder paste high precision layers to reflow ovens in PCB assembly lines with almost zero bridges or shortages.
| Specification
| Model | P3 | P6 | P12 | P15 |
| Accuracy | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm |
| PCB Size | 300 x 350 mm | 600 x 350 mm | 1200 x 350 mm | 1500 x 350 mm |
| Platform size | 320 x 400 mm | 700 x 400 mm | 1350 x 400 mm | 1650 x 400 mm |
| Stencil Size(mm) | 370*470-550*650 | 370*470-550*650 | 370*470-1500*650 | 370*470-1750*650 |
| PCB Thickness | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm |
| Stencil Positioning | Manual | Manual | Manual | Manual |
| Cycle Time | < 10 Sec. | < 10 Sec. | < 12 Sec. | < 12 Sec. |
| Power Consumption | 200 W | 200 W | 220 W | 220 W |
| Power Supply | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ |
| Air Pressure | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm |
| Squeegee Speed | 0-200mm/sec | 0-1200mm/sec | 0-200mm/sec | 0-200mm/sec |
| Dimension | 850x750x1650 mm | 1050x750x1650 mm | 1660x750x1650 mm | 2100x750x1650 mm |
| Weight | 280 Kg | 300 Kg | 356 Kg | 430 Kg |
| Squeegee Length | 250mm | 250mm | 250mm | 250mm |
| Platform Height | 950mm | 950mm | 950mm | 950mm |
| Option: Special size can be customized | ||||
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
I.C.T High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
Inspects internal solder joint integrity and detects hidden defects. | |
| SMT Cleaning Machine | Used for cleaning PCBs, stencils, fixtures, nozzles, etc. |
| PCB Cutting Machine | Cut the PCBA into the final product |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
| Customer Success Case Study – Saudi Arabia LED Factory
A Saudi customer built a full mid-volume SMT line from I.C.T using the PCB SMT Printing Automatic Machine, JUKI RS-1R mounter and L8 oven for network boards. Our engineers arrived in Riyadh, connected the printer to SMEMA belts, calibrated paste for 600×350mm panels and delivered seven days of training on high-precision settings and line flow. The PCB assembly line reached target UPH the same week with flawless paste feeding placement and no defects. The client praised the expert overseas support, protected packaging and detailed coaching that started the entire SMT production line instantly.
| Global Service & Training Support
I.C.T provides complete SMT production line support: free SMEMA layouts, 48-hour factory burn-in video, on-site conveyor linking, 7-10 day hands-on training camp, one-year spare parts, unlimited remote diagnostics by phone or screen share and regular yield improvement visits. Our 20 engineers cover 72 countries with 4-hour first response and 24/7 emergency hotline. Every PCB SMT Printing Automatic Machine completes 48-hour full-line aging and inspection in our 12,000m² ISO9001 factory. Customers enjoy worry-free SMT production lines, fast payback and long-term partnership.
| Customer Reviews
1600+ SMT lines in 72 countries trust I.C.T. They love custom belt plans for tight spaces, strong crates for ocean transport, week-long classes that make operators print experts, two-hour remote fixes that keep lines running and follow-up checks that raise output 18%. Factories expand constantly because total support means higher yield, lower scrap and true friendship.
| Certifications and Standards
All PCB SMT Printing Automatic Machine carry CE, RoHS, ISO9001:2015 and multiple patents. Conveyor tests and 100% checks meet EU, US and global standards for PCB assembly lines. These prove safe paste handling, no interference to next machine, strong docking and green operation – total confidence from the first board.
