| Precision Semi-Automatic Stencil Printer for Extra-Long PCB Assembly
The Semi Automatic Paste Printing Machine positions the semi-automatic stencil printer at the front of ultra-long PCB lines. Taiwan TBI linear guide-ways and SANYO stepper motor create perfectly matched motion for flawless paste on 1500mm boards. Suspension squeegee plus adjustable pressure and speed (with real-time gauges) deliver mirror-flat layers. Modular universal platform with alignment device handles single or double-sided PCBs from 0.2–6mm thick. Stencil arms extend from 370×470mm up to 2100×650mm. Automatic printing mode guarantees stable, high-quality output. Only 290W power and ≤15-second cycles make the Stencil Printer Smd perfect for LED walls, automotive dashboards, solar panels and large industrial controls.
| Feature
Custom pins and support blocks adapt instantly to any hole pattern on single or double-sided PCBs. Fast, accurate and fully adjustable positioning. Taiwan precision guide rails plus imported stepper motor deliver unbreakable stability. Manual squeegee lift simplifies paste refill and cleaning; smart limit sensors cut return time. This keeps super-long boards rock-steady inside the Semi-auto SMT Stencil Printer so paste lands exactly where needed for placement.
Direct squeegee linkage with two independent high-precision cylinders locks pressure perfectly. Double-slide rails eliminate any wobble. Large English touch screen offers teaching programs and one-tap switching between manual, semi-auto and full-auto modes. Only top-tier imported parts (Omron, Leuze, SMC, Delta, Samkoon) are used throughout the SMT Solder printer. Automatic printing produces exceptional quality board after board with virtually zero bridges or voids.
| Specification
| Model | P3 | P6 | P12 | P15 |
| Accuracy | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm |
| PCB Size | 300 x 350 mm | 600 x 350 mm | 1200 x 350 mm | 1500 x 350 mm |
| Platform size | 320 x 400 mm | 700 x 400 mm | 1350 x 400 mm | 1650 x 400 mm |
| Stencil Size(mm) | 370*470-550*650 | 370*470-550*650 | 370*470-1500*650 | 370*470-1750*650 |
| PCB Thickness | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm |
| Stencil Positioning | Manual | Manual | Manual | Manual |
| Cycle Time | < 10 Sec. | < 10 Sec. | < 12 Sec. | < 12 Sec. |
| Power Consumption | 200 W | 200 W | 220 W | 220 W |
| Power Supply | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ |
| Air Pressure | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm |
| Squeegee Speed | 0-200mm/sec | 0-1200mm/sec | 0-200mm/sec | 0-200mm/sec |
| Dimension | 850x750x1650 mm | 1050x750x1650 mm | 1660x750x1650 mm | 2100x750x1650 mm |
| Weight | 280 Kg | 300 Kg | 356 Kg | 430 Kg |
| Squeegee Length | 250mm | 250mm | 250mm | 250mm |
| Platform Height | 950mm | 950mm | 950mm | 950mm |
| Option: Special size can be customized | ||||
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
I.C.T High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
Inspects internal solder joint integrity and detects hidden defects. | |
| SMT Cleaning Machine | Used for cleaning PCBs, stencils, fixtures, nozzles, etc. |
| PCB Cutting Machine | Cut the PCBA into the final product |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
