| High-Speed PCB Stencil Printer for Large-Format SMT Lines
First Station for Long & Wide SMT Production Lines
The SMT Automatic PCB Stencil Printer places the PCB Stencil Printer at the front of large-format SMT lines. Taiwan TBI linear guide-ways and SANYO stepper motor drive speed match for stable paste on 1200mm boards. Suspension squeegee system makes printing more even. Blade pressure and printing speed is adjustable, precision pressure gauge and speed controller display give exact control. Modular universal bench with alignment device for PCB board and frame works with both single-sided and double-sided PCBs. Stencil frame arms can be adjusted for different size ranges from 370470mm to 1750650mm. Auto printing; stable and efficient printing quality. Only 12-second cycle and 220W power let the SMT Solder Paste Printing Machine support TV backplane, server board or industrial control SMT lines with high UPH.
| Feature
The pin and support block shall be suitable for different one-sided and double-sided PCB, and the pin of different size shall be suitable for different PCB holes. Operation simple, the positioning is accurate, and the fixed position is flexible and adjustable. Imported stepper motor Taiwan precision guide rail ensures stability, squeegee system can be lifted by manual conversion to add solder paste and cleaning operation, limit sensor flexible adjustment to reduce transportation travel. This locks long 1200mm boards steady in PCB assembly lines so the Semi Automatic Stencil Printer Solder keeps paste perfect for placers.
Direct connection squeegee structure. The squeegee is independently controlled by two high-precision cylinder to ensure accurate and stable pressure. The double slide positioning rails ensure the accuracy and stability of the squeegee. Touch screen operation. Friendly English MMI interface, teaching and navigation function. Operation mode: manual, semi-automatic and full-automatic. The core control parts adopt imported high-quality brands to ensure the stability and operability of the SMT Automatic Stencil Printer Solder. Auto printing, stable and efficient printing quality. This feeds uniform paste to large panels in PCB assembly lines with almost zero bridges or insufficient.
| Specification
| Model | P3 | P6 | P12 | P15 |
| Accuracy | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm |
| PCB Size | 300 x 350 mm | 600 x 350 mm | 1200 x 350 mm | 1500 x 350 mm |
| Platform size | 320 x 400 mm | 700 x 400 mm | 1350 x 400 mm | 1650 x 400 mm |
| Stencil Size(mm) | 370*470-550*650 | 370*470-550*650 | 370*470-1500*650 | 370*470-1750*650 |
| PCB Thickness | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm |
| Stencil Positioning | Manual | Manual | Manual | Manual |
| Cycle Time | < 10 Sec. | < 10 Sec. | < 12 Sec. | < 12 Sec. |
| Power Consumption | 200 W | 200 W | 220 W | 220 W |
| Power Supply | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ |
| Air Pressure | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm |
| Squeegee Speed | 0-200mm/sec | 0-1200mm/sec | 0-200mm/sec | 0-200mm/sec |
| Dimension | 850x750x1650 mm | 1050x750x1650 mm | 1660x750x1650 mm | 2100x750x1650 mm |
| Weight | 280 Kg | 300 Kg | 356 Kg | 430 Kg |
| Squeegee Length | 250mm | 250mm | 250mm | 250mm |
| Platform Height | 950mm | 950mm | 950mm | 950mm |
| Option: Special size can be customized | ||||
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
I.C.T High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
Inspects internal solder joint integrity and detects hidden defects. | |
| SMT Cleaning Machine | Used for cleaning PCBs, stencils, fixtures, nozzles, etc. |
| PCB Cutting Machine | Cut the PCBA into the final product |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
| Customer Success Case Study – Saudi Arabia LED Factory
A Saudi industrial panel maker ordered the complete large-format SMT line from I.C.T with the PCB Stencil Printer, JUKI high-speed mounter and L12 reflow oven for 1200mm boards. Our engineers flew to Riyadh, connected the printer to wide SMEMA conveyors, set paste for long panels and provided seven days of training on large-board handling and line balance. The PCB assembly line produced at full speed the next day with perfect paste coverage to placement and zero early defects. The client praised the quick overseas installation, reinforced crates and professional classes that launched the entire SMT production line immediately.
| Global Service & Training Support
I.C.T supports full large-format SMT production lines: free wide SMEMA designs, 48-hour factory aging video, site conveyor docking, 7-10 day large-board operator training, one-year spare parts, unlimited remote support via camera or chat and periodic line optimization visits. Our 20 engineers serve 72 countries with 4-hour first response and 24/7 emergency support. Every PCB Stencil Printer completes extended full-line burn-in and inspection in our 12,000m² ISO9001 facility. Customers gain reliable PCB assembly lines, faster returns and long-term growth partners.
| Customer Reviews
1600+ large-format SMT lines in 72 countries run on I.C.T. They appreciate custom wide layouts for big factories, extra-strong crates for long-distance travel, detailed large-panel training that boosts team skills, instant remote fixes that save full shifts and regular checks that increase output 19%. Plants expand quickly because total support means fewer defects, lower cost and real partnership.
| Certifications and Standards
Every PCB Stencil Printer holds CE, RoHS, ISO9001:2015 and multiple patents. Wide-board tests and 100% checks meet EU, US and global standards for PCB assembly lines. These confirm safe paste handling, stable large-frame docking, long-life parts and green operation – complete trust from day one.
| About I.C.T Company and Our Factory
I.C.T started in 2012 and now runs a modern 12,000m² factory in Dongguan, China, with 89 dedicated staff and 20 experienced engineers. We design, produce and test complete SMT production lines under strict ISO9001 standards. More than 1600 SMT lines in 72 countries prove our reliable quality and service. Eight global offices and local warehouses guarantee parts and engineer support within 48 hours anywhere. Customers grow with our honest pricing, fast delivery and lifetime free software upgrades.
