| SMT PCB Stencil Screen Printing Machine Basics
The SMT PCB Stencil Screen printing machine handles PCBs to 650x610mm with under 7-second cycles. High accuracy ±0.01mm repeat and 0.025mm print suit LED, automotive, electronics. Auto features include PCB calibration, pressure feedback, stencil cleaning. Glue printing option works well. The stencil PCB printer uses Windows 10 for easy navigation. Industry 4.0 and MES enable real-time info. I.C.T provides full planning and support. This SMT stencil printer automatic fits various needs in SMT PCB printing machine. Screen printing machine for SMT reduces manual work. Printer stencil PCB ensures consistent results.
| Feature
Arch bridge suspension direct-connects squeegee with two high-precision stepping motors. This controls separation speed and distance in multiple methods. Double slide rails ensure accuracy and stability before and after operation. Auto pressure adjustment with online feedback forms perfect paste. The SMT PCB Stencil Screen printing machine supports glue and various substrates. Imported top brands lower failure rate. Service life over ten years. It saves costs in screen printing machine for SMT. Ideal for fine-pitch in printer stencil PCB.
Unique belt conveyor prevents PCB stuck issues. Motor drives speed precisely up to 1500mm/s. Directions available left-right, right-left, or others. Side clamps and vacuum effectively clamp boards. Warpage under 1% allowed. The SMT stencil printer automatic lifts PCB to proper height programmatically. Magnetic pins or up-down tables add support. This guarantees smooth contact for quality prints in stencil PCB printer. Fast changeover under 5 minutes. Fits SMT PCB printing machine lines.
Dry, wet, vacuum, and manual modes available. CCD and cleaning parts separate for safety. Unique spray system applies from top to bottom evenly. Software controls alcohol and paper consumption. Special exhaust motor provides strong vacuum. The screen printing machine for SMT detects stencil holes with light compensation. Auto clean ensures perfect printing long-term. This maintains high standards in SMT PCB Stencil Screen printing machine.
| Specification
| Model | I.C.T-4034 | I.C.T5134 | I.C.T-5151 |
| Frame Size(mm) | 470*370 ~ 737*737 | 470*370 ~ 737*737 | 470*370 ~ 737*737 |
| PCB Size(mm) | 50*50 ~ 400*340 | 50*50 ~ 510*340 | 50*50 ~ 510*510 |
| Transport Direction | Left-Right; Right-Left; Left-Left; Right-Right | ||
| Support System | Magnetic Pin/Up-down table adjusted/support block | ||
| Clamping System | Side clamping(vacuum nozzle,Automation retractable Z pressure is option) | ||
| Printer Head | Two independent motorised printhead | ||
| Squeegee Type | Stainless steel(standard),plastic | ||
| Cleaning System | Dry, Wet, Vacuum | ||
| Inspection | 2D Inspection(Standard) | ||
| Power Supply | AC:220±10%,50/60HZ,3Kw | ||
| Control Method | PC Control | ||
| Dimension(mm) | 1220*1355*1500 | 1220*1355*1500 | 1220*1550*1500 |
| Model | I.C.T-6534 | I.C.T-6561 | I.C.T-9060 |
| Frame Size(mm) | 650*400 ~ 850*750 | 650*400 ~ 850*850 | 737*400 ~ 1100*900 |
| PCB Size(mm) | 50*50 ~ 650*340 | 80*50 ~ 650*610 | 80*50 ~ 900*600 |
| Dimension(mm) | 1330*1370*1500 | 1330*15450*1500 | 1580*1545*1500 |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
Our High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
| Customer Success Case Video
I.C.T engineers flew to North America for a beauty instrument client. They installed two SMT lines using the SMT PCB Stencil Screen printing machine. Work covered demand analysis, equipment calibration, full testing. Training taught vision matching, pressure balance, MES parameters. Lines passed production checks quickly with accurate small-pitch results. Client praised engineer knowledge, fast fixes, process improvements. This example shows I.C.T strength in global service for stencil PCB printer and SMT stencil printer automatic.
| Service and Training Support
I.C.T manages installation, maintenance, training for the SMT PCB Stencil Screen printing machine. On-site teams handle setup, optimization, fault records. Remote help analyzes issues instantly. Sessions cover MMI, teaching, navigation, new programs in 5-10 minutes. We review customer processes for efficiency and cost savings. Global warehouses stock parts. Long-term plans include adjustments and upgrades. This supports reliable operation in SMT PCB printing machine.
| Customer Reviews
Customers like I.C.T engineers for professional overseas work and quick responses. The screen printing machine for SMT runs with low failures. Packing protects during transport. Training makes operation simple. One said, "Auto features cut our cycle time." Another noted stable prints and good support for printer stencil PCB.
| Certifications and Standards
I.C.T holds CE, RoHS, ISO9001 for quality and safety. Patents include arc cleaning, paper control, spray, collision avoidance, dispensing, fault analysis, accuracy control, process, quality inspection, stencil system, separation speed, transport. These ensure innovation and compliance globally.
| About I.C.T Company and Our SMT Factory
I.C.T features in-house R&D and production with 89 staff, 20 engineers in 12000m². We serve 1600+ customers across 72 countries with fast growth. Factories use strict testing and quality management. We cover semiconductor to assembly full chains. Eight branches and warehouses provide local service. This delivers complete solutions for SMT PCB Stencil Screen printing machine integration.
