SS-330
I.C.T
| Quantity: | |
|---|---|
| Selective Soldering Wave Machine Overview
Fully designed and assembled in Dongguan, the I.C.T pcb selective soldering machine is the ultimate automatic selective soldering machine for high-mix, low-to-medium volume factories. Instead of moving the PCB, a feather-light cast-aluminum gantry on Panasonic servos and precision rails brings flux and solder right to the pins. Inline nitrogen heating produces mirror-bright fillets with almost no waste. Operators dial in every parameter—paths, temperatures, spray volume, wave height—on a big Windows touchscreen and store endless programs for instant job switches. Auto wave calibration, live CCD monitoring, German jet valve, and titanium pot make this pcb selective soldering machine a reliable workhorse that keeps first-pass yields sky-high.
| DIP Line Equipment List
German high-frequency jet valve drops micro-dots of low-solids flux (under 10%) repeatable to 0.02 mm. Pressurized tank plus digital flow meter lock pressure steady no matter how low the tank gets. Residue slides into a pull-out tray for two-second cleanup. Japanese SMC pneumatics and surface gauges make daily checks painless. An automatic extraction pump never lets supply drop. This flux system activates every pad perfectly on the pcb selective soldering machine.
Fully adjustable bottom IR is standard; top hot-air or additional IR optional. Open-grid layout plus thick high-temp insulation spreads heat evenly across the whole board. Premium heaters and plug-in motors run silent and maintenance-free for years. Boards exit perfectly flux-activated and warp-free, ready for flawless joints on the automatic selective soldering machine.
German electromagnetic pump and titanium pot generate a rock-steady mini wave that never leaks or drifts. Set N2 flow, solder temp, wave height, and auto-calibration straight from the touchscreen. Inline nitrogen gives shiny, full fillets and virtually zero dross. Laser checks height, nozzles self-clean, and 900 hours of video are stored for traceability. This is the bulletproof heart of the pcb selective soldering machine.
Three-section roller line plus pneumatic side and top clamps hold boards up to 20 kg dead-still. Heavy-duty rails and high-precision servos move PCBs smoothly station to station. Thick or double-sided assemblies clear easily. Built for 24/7 duty on any automatic selective soldering machine line.
CE-certified PLC, Cat-6 wiring, and full MES connectivity deliver lightning-fast response and bulletproof reliability. Guided wizards, picture-based edits, auto nozzle detection, and multi-language menus slash training time. Remote diagnostics keep the pcb selective soldering machine earning around the clock.
Large color touchscreen, step-by-step guides, one-tap live CCD, and voice alerts make running the machine dead simple. Switch instantly between English, Chinese, Japanese, or Russian. Custom tower lights and Wi-Fi upgrades keep everyone in the loop without leaving the floor.
| Specification
| On-line Selective Wave Soldering Machine | ||||
| Model | I.C.T SS540 | I.C.T SS550 | I.C.T SS550P1 | I.C.T SS550P2 |
| On-line Modular | Spray + Preheating & Soldering | Spray + Preheating + Soldering | Spray + Preheating + Soldering +Soldering | Spray + Preheating + Soldering + Soldering+ Soldering |
| Soldering System | ||||
| Nozzle Quantity | 1 | 1 | 2 | 3 |
| Solder Pot Quantity | 1 set | 1 set | 2 set | 3 set |
| Double Pot (Option) | N/A | Option | Option | Option |
| Solder Pot Power | 2.35kw | 2.35kw | 4.70kw | 7.05kw |
| Flux System | ||||
| Flux Storage Tank | 1L | 1L | 2L | 2L |
| Flux Support | Flux Alarm, Automatic | |||
| Spray Nozzle | Germany Jet Valve (Spot and line spraying) 1 set | |||
| Spray Nozzle Size | 130um (180um, 210um Option) | |||
| Spray Speed | 0~20mm/s | |||
| Spray Nozzle Move Speed | 0~400mm/s | |||
| Preheating System | ||||
| Preheating Mode | Hot air and IR | Hot air and IR | Hot air and IR | Hot air and IR |
| Preheating Area | L500*W500mm | L500*W500mm | L500*W500mm | L500*W500mm |
| Preheating Zone | Top hot air: 2, Bottom IR: 1 | |||
| Bottom Preheating Power | Max.12kw | |||
| Top Preheating Power | Max.6kw | |||
| Warm-up Time | Approx.15min (setting 150℃) | |||
| Control Mode | PC+PLC | |||
| Transport System | ||||
| PCB Size (with fixture) | 120*60~500*500mm | |||
| PCB Replacement | Online | |||
| PCB Top Clearance | 120mm | |||
| Transport Height | 900±20mm | |||
| Transport Width | 60~500mm | |||
| Dimension：mm | L1850*W1850*H1480 | L2560*W1750*H1480 | L2560*W1950*H1480 | L2600*W1950*H1480 |
| Weight | Approx: 800kg | Approx: 1200kg | Approx: 1300kg | Approx: 1500kg |
| DIP Line Equipment List
Our DIP production line offers advanced tools for efficient and precise PCB assembly. The fully automated DIP line includes a DIP insertion line for accurate component placement, a wave loader for smooth PCB entry, a wave unloader for safe exit, and an assembly belt line for final checks. This high-quality PCB DIP production line ensures stable operation, reliable THT insertion, and cost-effective assembly, meeting diverse industry needs. With modular designs and global support from I.C.T, it boosts productivity for through-hole tasks.
| Product Name | Purpose in DIP Line |
|---|---|
Automatically places components onto PCBs with precision for DIP production line. | |
Melts solder to form solid joints on PCBs during THT plug-in process. | |
Applies solder selectively to specific areas for accurate THT assembly | |
| Post-wave Inline AOI | Inspects solder joints and placement defects on DIP assembled PCB. |
| Customer Success Video
Early 2025, a major Vietnamese camera-brand supplier flew in for final acceptance of their new pcb selective soldering machine. Our engineers loaded their real production boards, ran complete cycles while the customer watched perfect THT joints form live on the CCD, then trained their techs for two full days on programming, daily care, and troubleshooting. They left 100% ready to hit volume the day the crate arrived—classic I.C.T worldwide partnership.
| Professional Service and Training
We handle everything from factory acceptance and crating to installation, startup, and lifetime support. Twenty senior engineers plus local teams in 72 countries provide on-site or remote training whenever you need it. Spare-parts warehouses on three continents and true 24/7 hotlines keep your automatic selective soldering machine at peak uptime for decades.
| Customer Praise
Customers constantly praise our patient, expert engineers who train thoroughly at acceptance and startup. They love the pinpoint flux accuracy, rock-solid wave, and how fast the pcb selective soldering machine pays for itself in higher yields and zero rework. Export crates arrive flawless, and same-day remote fixes have turned first-time buyers into lifelong partners worldwide.
| Industry Certifications
Every pcb selective soldering machine ships with CE safety certification, RoHS compliance, ISO9001 quality system, and multiple patents on jet valves, electromagnetic pumps, and laser calibration. These globally trusted marks prove you’re getting safe, green, field-proven technology you can rely on anywhere.
| About I.C.T Company and Factory
Since 2012 we’ve grown into a 12,000 m² state-of-the-art campus with 89 team members, 20 dedicated engineers, and 8 global branches. Everything—R&D, fabrication, assembly, and burn-in testing—happens in-house. We serve over 1,600 factories in 72 countries with complete turnkey SMT and THT solutions, and every pcb selective soldering machine leaves backed by rigorous inspection and proven quality systems.
