| Efficient SMT Router for Precise Depaneling
The SMT router finds use in factories making smartphones, smart wearables, tablets, automotive electronics, medical devices, and aerospace parts. It handles PCB sizes from 340×380mm to 450×600mm and thicknesses of 0.5 to 5.0mm without difficulty. The new CCD vision system detects all mark types and corrects positioning automatically. Spindle speed reaches 80,000rpm for cuts that reduce stress, keep high accuracy, limit inertia, and respond quickly. Dual platforms process different boards at once or combine into one larger area. Ion air gun removes static so dust cannot settle. Sensors watch the cutter in real time. The separate vacuum collector pulls strongly with low noise. Controls stay simple and stable for everyday operation in production.
| Feature
Transmission System
Panasonic servo motors from Japan pair with high-precision screw rods to control motion exactly. Taiwan guide rails and ball screws maintain accuracy over long hours. The thicker mechanical structure absorbs vibrations and holds firm stability. Flexible tank chains route cables cleanly, avoiding any contact with moving parts. The X-axis dust-proof design lowers cleaning needs and cuts maintenance costs. These elements work together without fail. The SMT router keeps precise positioning and runs reliably through continuous shifts in busy factories.
Router System
High-definition vision aligns directly with the milling cutter for easy calibration. Tool breakage detection sounds an alarm the instant a cutter fails or wears. Optional automatic tool changer allows work to continue without stopping. Ion air gun clears static from PCB surfaces and stops dust from sticking. Imported high-speed spindle cuts with low stress, high precision, small inertia, and fast response. These features ensure clean edges and protect boards. The Inline PCB Board Cutting machine SMT router delivers consistent quality every time.
Platform System
Y-axis uses slide rails and servo motor for solid stability. Emergency stops on both sides, safety covers, and light curtains provide protection. Start buttons require two-hand pressing to begin safely. Honeycomb porous base grips boards firmly and fits many fixtures. Dual platforms handle separate jobs or merge for larger work. This setup makes the PCB Board Cutting machine secure and flexible for high-volume lines.
Control System
Industrial computer and CNC controller resist factory electrical noise. Production logs track every job for quality records. Interface meets CE standards and changes programs quickly. Coaxial CCD shows live cutting view. Operators learn fast and keep results steady. The PCB SMT router operates reliably in real production conditions.
Detail Display
Convection fan keeps temperatures even inside. Side door sensors stop motion if opened. ESD interface protects against static damage. Optional auto tool changer swaps bits without pause. Broken knife sensor checks cutter constantly. Pneumatic struts lock doors securely. These details add safety and ease to daily use of the Inline PCB Board Cutting machine.
| Specification
| Model | I.C.T-5700M | I.C.T-5700L | I.C.T-5700LL |
| Pcb Size(Double platform,Special size optional) | 290*350mm | 350*450mm | 450*500mm |
| PCB thickness | 0.3~6.0mm | ||
| Weight(with vacuum cleaner) | 1000kg | ||
| Dimension | 1075*1430*1460mm | 1125*1530*1460mm | 1225*1530*1460mm |
| Dust Collection Method | Vacuum cleaning | ||
| Air volume of vacuum cleaner | 28~35cm3/min | ||
| Vacuum cleaner Dimension | 640*785*1760mm | ||
| Voltage of the Dust Collector | 380V,50/60HZ,3kw | ||
| SMT Line Equipment List
I.C.T make real High-Quality PCBA Production Line. Vacuum loader give board clean. Auto printer put paste right. Placer set chip true. Many zone reflow solder hard. Good AOI find all bad. Line stay tight. Yield high. Cost low. No play. Make for hard work car health light. Board come ready real world. We back full.
| Product Name | Purpose in SMT Line |
|---|---|
| SMT Line | Turnkey Ful-auto SMT assembly line |
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| Customer Success Video
An Algerian customer building feature phones came to our factory with over ten PCB panels and full components. We ran the complete SMT line in front of them: automatic printer applied paste, SPI checked quality, RX-8 placed small parts, RS-1R handled larger ones, tray feeder supplied shields, reflow oven soldered boards, AOI inspected defects, and the I.C.T SMT router separated panels cleanly with no stress. The process moved smoothly from start to finish. They watched high efficiency and perfect cuts closely. The customer left satisfied and approved the equipment fully.
| Service and Training Support
I.C.T engineers install the machine on site and train operators thoroughly. They cover safe use, programming, tool care, and daily maintenance for the SMT router. Remote help arrives fast, and spare parts ship quickly worldwide. Service centers respond to issues without delay. Ongoing advice adjusts processes as needs change. This full support keeps machines running and gives customers peace of mind.
| Client Testimonials
Customers thank our engineers for quick, clear solutions and expert help. They praise the SMT router for precise cuts and gentle board handling. Many note the strong, careful packaging that delivers machines safely. Fast answers to questions build real trust. Overall, clients value I.C.T equipment and support that keep production steady.
| Certifications and Standards
CE confirms full safety compliance. RoHS limits harmful materials. ISO9001 ensures strict quality control. Multiple patents protect our designs. These certifications prove the SMT router meets global standards for safety and reliability.
| About I.C.T Company and Factory
I.C.T runs its own R&D and production with many skilled engineers. Staff totals 89 people. The company started in 2012 and grew quickly. It now serves over 1600 customers in more than 72 countries through 8 branches. Modern factories use strict testing and ISO9001 quality systems. Every machine gets careful checks before shipping. We focus on innovation and reliable service worldwide.
