SMT PCB Loader Unloader
I.C.T
| Quantity: | |
|---|---|
| Advanced NG/OK SMT Unloader for Quality Lines
Smart SMT Ng/ok Unloader for Quality Management
The I.C.T SMT Ng/ok Unloader is the efficient PCB SMT Unloader machine that receives boards from AOI or SPI, reads the inspection signal, and stacks OK boards in one magazine while sending NG boards to another. Standard or full CE version—both have reinforced hardware, precise sensors, and flexible software. The SMT Ng/ok Unloader reduces rework time, enhances quality tracking, runs three shifts smoothly, and works as an Automatic Magazine PCB Loader SMT Ng/ok Unloader in your line.
| Detailed Product Features
The SMT Ng/ok Unloader uses thicker steel rails and base that comply with ISO and CE standards. It stays stable during constant use. Maintenance is quick and easy. The machine offers long-term reliability in high-volume factories.
Reliable Sensor Detection
High-quality sensors and bright lights provide clear OK/NG status. Buttons respond fast. The SMT Ng/ok Unloader detects inspection results accurately and keeps sorting steady without errors.
The system supports Industry 4.0 standards. Add IPC-CFX, Hermes, or other protocols when needed. Load new settings in under two minutes. The SMT Ng/ok Unloader connects to factory software and adjusts automatically.
Separate lowering units place OK and NG boards gently. The SMT Ng/ok Unloader fills two magazines without damage. Boards stay organized for rework or packing.
SMEMA interface is standard and ready. Optional smart links available. The SMT Ng/ok Unloader fits your line quickly and maintains steady flow during changeovers.
| Specification
| Model | DUL-M | DUL-L | DUL-LL | DUL-XL |
| Dimension(mm) | 1730*1530*1250 | 2065*1630*1250 | 2660*1760*1250 | 2660*1900*1250 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 | 50*50-530*460 |
| Rack Size(mm) | 355*320*563 | 460*400*563 | 535*460*563 | 535*530*563 |
| Control System | PLC | |||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | |||
| Weight | 340 Kg | 380 Kg | 420 Kg | 460 kg |
| SMT Line Equipment List
Our turnkey High-Quality SMT Production Line delivers fully automatic, high-speed, and ultra-reliable PCBA manufacturing. The proven setup starts with the Vacuum and Magazine Loader, moves to a precision automatic printer for perfect solder paste application, continues with high-speed pick-and-place machines for accurate component placement, passes through a stable reflow oven for strong solder joints, and finishes with advanced AOI inspection to catch any defect. Every machine communicates seamlessly, reducing labor and boosting first-pass yield. This complete solution meets automotive, medical, consumer, and LED industry standards while keeping operating costs low and uptime extremely high.
| Customer Success Story
In 2024 our engineers flew to Finland to install a complete LED panel production line for a leading European lighting manufacturer. The line included the SMT Ng/ok Unloader, 1.5 m automatic printer, SM482PLUS placement machine, L8 reflow oven, cooling buffers, linking conveyors, board splitter, and solder paste mixer. Our team completed installation, debugging, and operator training in only five days. The line reached full speed on the first production day with zero defects. The customer praised the accurate sorting of the SMT Ng/ok Unloader and perfect machine communication. They passed the strict European audit easily and ordered another line soon after.
| Professional Service and Training
In 2024 our engineers flew to Finland to install a complete LED panel production line for a leading European lighting manufacturer. The line included the SMT Ng/ok Unloader, 1.5 m automatic printer, SM482PLUS placement machine, L8 reflow oven, cooling buffers, linking conveyors, board splitter, and solder paste mixer. Our team completed installation, debugging, and operator training in only five days. The line reached full speed on the first production day with zero defects. The customer praised the accurate sorting of the SMT Ng/ok Unloader and perfect machine communication. They passed the strict European audit easily and ordered another line soon after.
| Customer Praise
“Engineers arrived quickly and solved our problem the same day.” “The NG/OK SMT Unloader is stable and very reliable.” “Packing was safe; machines arrived perfect after shipping.” “They respond fast and help us improve quality control.”
| I.C.T Quality Certificates
Every NG/OK SMT Unloader has CE, RoHS, ISO9001 certifications and multiple technical patents. Each machine goes through strict testing before shipment to guarantee top quality and safety for customers worldwide.
| Professional SMT Solution Provider
Founded in 2012, I.C.T now runs a modern 12,000 m² factory with nearly 90 employees and our own R&D center. We design, build, and test everything in-house under strict quality systems. Serving over 1,600 customers across 72 countries, we have grown fast by always putting customer success first. From a single Vacuum and Magazine Loader to complete turnkey lines, I.C.T is the long-term partner factories trust worldwide.
