| I.C.T Acrab-Series Nitrogen Wave Soldering Machine
This is the machine that solders without oxygen. Three sizes: 350, 450, 615 mm. You choose. Nitrogen turns black dross into silver savings. Wave height never moves more than half a millimeter. Temperature never lies. PC+PLC watches everything. Tool-free doors open in seconds. Factories in seventy-two countries run it. They sleep better. You will too. The best nitrogen wave solder machine for sale is waiting.
| Feature
The drawer slides out. Inside sits a Japanese Kuroda nozzle that never clogs. Stepper motor moves it exactly. Flux lands even, thin, perfect. Automatic wash keeps the chamber white. Add nitrogen here and the machine becomes the cleanest nitrogen wave soldering machine money can buy.
Three zones. 1800 mm of heat. Hot air and infrared hit the board together. Fifteen minutes to 250 ℃. Thick insulation holds the heat like a fist. Temperature swings only two degrees. Drawer modules pull out. No tools. Change a zone in minutes. Top preheating is ready when you need it.
Chain runs true. Double-hook titanium fingers grip hard. Heavy automotive boards never fall. Speed stays within two millimeters per minute. Fingers clean themselves. Width adjusts by motor if you want. The conveyor was born to feed a nitrogen wave soldering machine without drama.
Cast-iron pot. Enamel skin. 500–700 kg of clean solder. Dual wave rises and falls within half a millimeter. Nitrogen blanket above. Automatic dross channel below. Oxidation dies. Joints shine like mirrors. Solder bill drops ninety percent. This is what a real Nitrogen Wave Soldering Machine does.
Big fans hit from the top. Add bottom fans when boards are thick. Temperature falls fast. Components stay cool. Solder freezes bright. No thermal shock. No ugly joints. The board leaves happy.
Touch screen. Simple. PC+PLC brain. PID keeps temperature honest. Standby mode saves tin and power. Alarms remember everything. Emergency hand crank works when power dies. CE and UL stamps on the plate. Any operator learns it in one shift and trusts it for life.
| DIP Line Equipment List
| Model | Acrab 350 | Acrab 450 |
| Dimension(mm) | 4420X1420X1750 | 4420X1520X1750 |
| Power Supply | 3P5W,380/220V 50Hz | 3P5W,380/220V 50Hz |
| Startup Power | 33kw | 33kw |
| Operation Power | 8kw | 8kw |
| Control System | PC+PLC | PC+PLC |
| Preheating Zone | 3 | 3 |
| Preheating Length | 1800mm | 1800mm |
| Preheating Temp. | (Room Temperature)-250°C | (Room Temperature)-250°C |
| PCB Width(mm) | 50-350mm | 50-450mm |
| Finger | Spring Pressing Finger (Standard); Option:Spring Pressing Finger, Duck Mouth Finger | |
| Solder Pot Capacity | Lead-free 500kg | |
| Machine Weight(kg) | Approx.1600kg | Approx.1900kg |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| DIP Line Equipment List
Buy the full automatic DIP line and the Acrab nitrogen system together. Insertion → loader → Nitrogen Wave Soldering Machine → unloader → inspection belt. Zero defects. Almost zero dross. Modular, grows when you grow. Global service keeps it running 24/7. The smartest nitrogen wave solder machine for sale on the planet.
| Product Name | Purpose in DIP Line |
|---|---|
| Automatic Insert Machine | Automatically places components onto PCBs with precision for DIP production line. |
Melts solder to form solid joints on PCBs during THT plug-in process. | |
Applies solder selectively to specific areas for accurate THT assembly | |
Inspects solder joints and placement defects on DIP assembled PCB. | |
Board input machine and board output machine | |
| DIP Peripheral | Peripheral products of DIP production line |
| Customer Success Video
Our engineers landed in Mexico. One factory solders two different automotive boards on the same Acrab 350. Custom fixtures. Zero bridges. Perfect fillets. Same plant runs our coating line and SS-540 selective. They filmed their smile and sent it to us. Watch it.
| Expert Services and Training
We install. We train. We leave nothing behind except perfect solder joints. Twenty engineers overseas. 24-hour online. Spare parts fly the same day. Your line hits 99.5 % first-pass yield in a week. Then we keep coming back until you forget we ever left.
| Customer Testimonials
“Packing is very safe and professional.” “Your engineers are patient and skilled; they solved all problems in two days.” “The wave soldering machine runs stably with almost no dross – real energy saving!” “Response speed is amazing; questions answered within one hour anytime.”
| Quality Certifications
CE. RoHS. ISO9001:2015. Invention patents. Every Nitrogen Wave Soldering Machine runs seventy-two hours full load in Dongguan before it sees your floor.
| About I.C.T Company and Factory
Dongguan. 12,000 m². Ninety people who build every critical parts themselves. 1,600 customers. Seventy-two countries. Eight overseas offices. Twenty field engineers with passports always ready. We are not the biggest. We are the ones who show up.
