| Smart Ng/ok Magazine Unloader for SMT Lines
The I.C.T Ng/ok Magazine Unloader is the efficient machine that receives boards from inspection, checks the pass/fail signal, and stacks OK boards in one magazine and NG boards in another. Standard or full CE version—both have stronger hardware, accurate sensors, and flexible controls. The Ng/ok Magazine Unloader helps track quality, reduces rework steps, runs three shifts smoothly, and works well as an SMT PCB Vacuum Magazine Loader or SMT PCB Loader Unloader in your line.
| Detailed Product Features
The Ng/ok Magazine Unloader uses thicker steel for frame and base. All parts follow ISO and CE standards. The machine stays stable during constant use. Maintenance is simple and fast for your team.
High-quality sensors and bright lights show OK/NG status clearly. Buttons respond quickly. The Ng/ok Magazine Unloader handles inspection data without errors and keeps sorting reliable.
The system supports Industry 4.0 features. Add IPC-CFX, Hermes, or other protocols anytime. Change settings fast for new products. The Ng/ok Magazine Unloader connects to factory software and adjusts automatically.
Separate lowering units place OK and NG boards carefully. The Ng/ok Magazine Unloader fills two magazines without damage. Boards stay organized for rework or packing.
SMEMA interface is standard and ready. Optional advanced links available. The Ng/ok Magazine Unloader integrates into your line rapidly and maintains steady flow during changes.
| Specification
| Model（Loader) | LD-M | LD-L | LD-LL | LD-XL |
| Dimension(mm) | 1330*765*1250 | 1650*845*1250 | 1800*909*1250 | 1800*970*1250 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 | 50*50-530*460 |
| Rack Size(mm) | 355*320*563 | 460*400*563 | 535*460*563 | 535*530*563 |
| Control System | PLC | |||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | |||
| Weight | 160 Kg | 220 Kg | 280 Kg | 340 Kg |
| Model （Unloader) | UL-M | UL-L | UL-LL | UL-XL |
| Dimension(mm) | 1730*765*1250 | 2065*845*1250 | 2660*909*1250 | 2660*970*1250 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 | 50*50-530*460 |
| Rack Size(mm) | 355*320*563 | 460*400*563 | 535*460*563 | 535*530*563 |
| Control System | PLC | |||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | |||
| Weight | 180 Kg | 240 Kg | 300 Kg | 360 Kg |
| SMT Line Equipment List
Turnkey means bare board in, finished panel out, no babysitting. The PCB Unloader Loader feeds clean at the front, catches clean at the back. Printer hits perfect paste. Placer drops every component dead-center. Reflow solders solid. AOI checks everything. All stations stay locked in sync. Labor stays thin. First-pass yield stays north of 99.5 %. Uptime stays brutal. Automotive, medical, consumer, LED—standards crushed, costs crushed.
| Customer Success Story
In 2024 our engineers flew to Finland to install a complete LED panel production line for a leading European lighting manufacturer. The line included the Ng/ok Magazine Unloader, 1.5 m automatic printer, SM482PLUS placement machine, L8 reflow oven, cooling buffers, linking conveyors, board splitter, and solder paste mixer. Our team completed installation, debugging, and operator training in only five days. The line reached full speed on the first production day with zero defects. The customer praised the accurate sorting of the Ng/ok Magazine Unloader and perfect machine communication. They passed the strict European audit easily and ordered another line soon after.
| Professional Service and Training
I.C.T provides full support: on-site or remote installation, free training for operators and technicians, 24-hour technical hotline, worldwide spare parts delivery, and regular maintenance plans. Our experienced team ensures your Ng/ok Magazine Unloader runs at best performance with almost no unplanned stops.
| What Customers Say
“Engineers arrived quickly and solved our problem the same day.” “The Ng/ok Magazine Unloader is stable and very reliable.” “Packing was safe; machines arrived perfect after shipping.” “They respond fast and help us improve quality control.”
| Our Quality Certificates
| About Us and Factory
Since 2012, I.C.T has grown quickly with our own R&D team, full production lines, and nearly 90 employees. We have strict testing and quality systems in our modern factory. We serve over 1,600 customers in 72 countries. From one Ng/ok Magazine Unloader to complete turnkey solutions, we are your trusted partner for long-term success.
