| Advanced SMT Steel Stencil Printer
The SMT Steel stencil printer machine from I.C.T sets a new standard for automated solder paste printing in SMT processes. It offers high positional accuracy with repeated positioning at ±0.01mm and printing precision up to 0.025mm, making it ideal for consumer electronics, automotive parts, and LED manufacturing. This machine supports glue printing and automatic controls to enhance production efficiency while cutting costs. Features like programmable squeegee pressure, automatic PCB calibration, and stencil cleaning ensure consistent quality. With models like I.C.T-4034 to I.C.T-9060, it handles PCB sizes from 50x50mm to 900x600mm. Built with imported components from brands like Panasonic and SMC, it guarantees stability and a long service life. Compliant with SMEMA standards, this SMT Steel stencil printer machine integrates seamlessly into smart factories for maximum automation.
| Feature
The print system in our SMT Steel stencil printer machine uses an arch bridge suspension structure with direct connection squeegee controlled by two high-precision stepping motors. This setup provides accurate and stable pressure, ensuring perfect solder paste forming. Double side slide positioning rails maintain stability during operations. It supports squeegee speeds from 10 to 200mm/sec and angles of 60°, 55°, or 45°. Programmable motors allow multi-method separation between squeegee, stencil, and substrate. This results in high-quality prints for fine-pitch components, reducing defects in electronics assembly. Ideal for high-volume runs, it minimizes waste and improves overall yield.
Our transport system in the SMT Steel stencil printer machine features a unique belt conveyor that prevents PCB sticking. Motor-controlled speed and precise stop positions allow flexible entry and exit directions. Side clamps and optional vacuum hold the PCB firmly for smooth contact with the stencil. It supports transport heights of 900±20mm and speeds up to 1500mm/s. This design ensures reliable handling of various PCB types, from thin to thick boards. By preventing misalignment, it boosts production efficiency and quality in automotive and consumer electronics.
Dry, wet, and vacuum cleaning modes, plus manual options, keep the stencil clear. A unique spray system evenly distributes cleaner from top to bottom, controlled by software for alcohol and paper use. Special exhaust motor provides strong vacuum for effective residue removal. CCD and cleaning parts are separate for easy maintenance. This system in our smt auto printing machine saves materials and ensures consistent print quality over long runs.
Optional Stencil Inspection
Through light source compensation and CCD, the stencil inspection detects hole blockages quickly. It judges cleanliness and triggers automatic cleaning for perfect prints. This option in the printer SMT enhances quality control, preventing defects in solder paste application.
| Specification
| Model | I.C.T-4034 | I.C.T5134 | I.C.T-5151 |
| Frame Size(mm) | 470*370 ~ 737*737 | 470*370 ~ 737*737 | 470*370 ~ 737*737 |
| PCB Size(mm) | 50*50 ~ 400*340 | 50*50 ~ 510*340 | 50*50 ~ 510*510 |
| Transport Direction | Left-Right; Right-Left; Left-Left; Right-Right | ||
| Support System | Magnetic Pin/Up-down table adjusted/support block | ||
| Clamping System | Side clamping(vacuum nozzle,Automation retractable Z pressure is option) | ||
| Printer Head | Two independent motorised printhead | ||
| Squeegee Type | Stainless steel(standard),plastic | ||
| Cleaning System | Dry, Wet, Vacuum | ||
| Inspection | 2D Inspection(Standard) | ||
| Power Supply | AC:220±10%,50/60HZ,3Kw | ||
| Control Method | PC Control | ||
| Dimension(mm) | 1220*1355*1500 | 1220*1355*1500 | 1220*1550*1500 |
| Model | I.C.T-6534 | I.C.T-6561 | I.C.T-9060 |
| Frame Size(mm) | 650*400 ~ 850*750 | 650*400 ~ 850*850 | 737*400 ~ 1100*900 |
| PCB Size(mm) | 50*50 ~ 650*340 | 80*50 ~ 650*610 | 80*50 ~ 900*600 |
| Dimension(mm) | 1330*1370*1500 | 1330*15450*1500 | 1580*1545*1500 |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
Our High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
| Customer Success Video
In 2025, our engineer Tony visited a client in Uzbekistan to inspect and train on their newly purchased SMT and DIP production line, including peripheral equipment. The video captures Tony leading the process, with our team explaining equipment principles, operations, and maintenance. For challenging programming parts, we used repeated demos and patient guidance, encouraging hands-on practice until the client mastered it efficiently. After one week, they operated and maintained the equipment confidently, highly appreciating our professionalism. This successful training and inspection marked a perfect conclusion to the project.
| Service and Training Support
At I.C.T, we offer comprehensive service and training to maximize your equipment's potential. Our global network includes engineers like Tony for on-site installation, maintenance, and troubleshooting. We provide customized training programs covering operation, programming, and safety for the SMT stencil printer custom. Online support ensures quick responses to queries, minimizing downtime. Regular updates and spare parts supply keep your line running smoothly. With over 25 years in electronics manufacturing, our team helps optimize processes for better efficiency. This commitment builds long-term partnerships worldwide.
| Customer Reviews
Our customers praise I.C.T engineers like Tony for their expertise and patient training. They love the SMT stencil printer machine for its reliability and precision. Many highlight our secure packaging that ensures safe delivery without damage. Fast responses to issues keep production on track, earning trust globally.
| Certifications and Standards
I.C.T holds key certifications like CE, RoHS, and ISO9001, ensuring compliance with global standards. We also have multiple patents for innovative designs in SMT equipment. These credentials reflect our focus on quality, safety, and environmental responsibility. They assure customers of reliable products built to last.
| About I.C.T Company and Our SMT Factory
I.C.T is a leading provider of electronics manufacturing solutions with our own R&D and production teams. With 89 staff and 20 engineers in a 12,000m² facility, we've grown rapidly since 2012. Serving over 1,600 customers in 72 countries, we cover SMT, DIP, and assembly needs. Our factory follows strict testing processes and ISO9001 quality management for superior products. This global reach and local service create cross-value for partners.
