| Efficient Offline PCB Depaneling Router Machine
You’ll find this PCB depaneling router machine at work in smartphones, smart wearables, home devices, tablets, car electronics, medical gear, and even aerospace. It takes boards sized from 340×380mm all the way to 450×600mm, with thickness 0.5 to 5.0mm. The latest CCD vision setup recognizes every kind of mark and fixes alignment on its own. Spindle spins up to 80,000rpm for low-stress, high-accuracy cutting. Two platforms let you run different jobs together or merge them into one big work area. Ion air gun wipes away static so dust doesn’t stick. Sensors watch the cutter constantly. Separate dust collector runs quiet yet powerful. Everything is built for straightforward daily use.
| Feature
Transmission System
A unique dust-proof design on the X-axis keeps maintenance simple and costs down. Flexible tank chains hold wires neatly and stop them from tangling with moving parts. Thicker, stronger frame gives rock-solid stability during long runs. Imported Panasonic servo motors team up with precise Taiwan guide rails and screw rods for smooth, exact motion every time. All these pieces fit together so the PCB depaneling router machine stays dependable shift after shift in busy shops.
Router System
Imported high-speed spindle cuts with low force, quick reaction, and tight accuracy every pass. Ion air gun blasts static off the board surface so dust can’t settle. Optional automatic tool changer keeps the line rolling without pauses for swaps. Broken-tool detection triggers an instant alarm if anything goes wrong. High-definition CCD camera lines up perfectly with the cutter for quick, spot-on setup. Together, these make the PCB depaneling router machine a smooth, worry-free performer on the floor.
Platform System
Honeycomb porous base grabs boards firmly and works with many types. Dual platforms accept standard or custom fixtures without fuss. Operators press two start buttons at once for safe startup. Safety light curtains, full covers, and dual emergency stops protect everyone nearby. Servo motors plus slide rails keep the Y-axis steady and strong. This whole setup turns the PCB depaneling router machine into a safe, flexible workhorse for real production demands.
Control System
Real-time CCD display lets operators see exactly what’s happening. Simple, easy-to-learn interface meets CE standards and switches programs fast. Data logs record every run for solid quality tracking. Dedicated CNC controller plus industrial computer fight off factory interference well. High control precision and steady performance come standard. This system keeps the PCB depaneling router machine straightforward to run and trustworthy day in, day out.
Detail Display
Self-locking pneumatic struts hold doors open steady and safe. Broken-knife sensor checks cutter wear constantly. Optional auto tool changer swaps bits without stopping work. ESD interface guards sensitive parts from static shocks. Side-door safety sensors halt motion if doors open. Convection fan keeps inside temperature even. Each small touch adds real safety and convenience to everyday use of the PCB depaneling router machine.
| Specification
| Model | I.C.T-5700M | I.C.T-5700L | I.C.T-5700LL |
| Pcb Size(Double platform,Special size optional) | 290*350mm | 350*450mm | 450*500mm |
| PCB thickness | 0.3~6.0mm | ||
| Weight(with vacuum cleaner) | 1000kg | ||
| Dimension | 1075*1430*1460mm | 1125*1530*1460mm | 1225*1530*1460mm |
| Dust Collection Method | Vacuum cleaning | ||
| Air volume of vacuum cleaner | 28~35cm3/min | ||
| Vacuum cleaner Dimension | 640*785*1760mm | ||
| Voltage of the Dust Collector | 380V,50/60HZ,3kw | ||
| SMT Line Equipment List
I.C.T make real High-Quality PCBA Production Line. Vacuum loader give board clean. Auto printer put paste right. Placer set chip true. Many zone reflow solder hard. Good AOI find all bad. Line stay tight. Yield high. Cost low. No play. Make for hard work car health light. Board come ready real world. We back full.
| Product Name | Purpose in SMT Line |
|---|---|
| SMT Line | Turnkey Ful-auto SMT assembly line |
| PCB loader machine | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| Customer Success Video
Customers from Algeria building feature phones arrived at our plant to check the line themselves. They brought along more than ten panels plus all their components. We fired up the full SMT process right there for them to watch. Automatic printer started it off, SPI checked solder, RX-8 handled small parts, RS-1R took the bigger ones, tray feeder added shield covers, reflow oven finished soldering, AOI inspected everything. Last step, our I.C.T PCB depaneling router machine separated boards with perfect clean edges. The entire run went smooth as clockwork. Visitors saw strong efficiency and flawless results up close and left completely happy with what they saw.
| Service and Training Support
Worldwide service centers answer questions fast and keep machines running. Spare parts ship quickly to cut any downtime. Remote support solves many issues over the phone or screen. On-site training teaches safe operation, programming, tool handling, and routine care for the PCB depaneling router machine. Experienced engineers handle installation from day one. Ongoing tips help improve line performance over the years. This complete backup gives customers real confidence and the best return on their investment.
| Client Testimonials
Many buyers tell us our engineers solve problems fast and explain things clearly. They love the steady accuracy and neat cuts from our machines. Careful packing and secure shipping mean equipment always arrives in top shape. Quick replies to any question build lasting trust. Overall, customers say I.C.T stands out for quality gear and outstanding support.
| Certifications and Standards
Multiple patents back our own technology innovations. ISO9001 ensures tight quality control at every step. RoHS confirms we meet environmental rules. CE mark proves full safety compliance. These official stamps show the PCB depaneling router machine and all our products reach high worldwide standards without compromise.
| About I.C.T Company and Factory
Strict quality systems and thorough testing run through our modern factories. Large engineering teams drive our own research and production. Growth has come fast, now reaching over 1600 customers in more than 72 countries. Every unit, including each PCB depaneling router machine, passes careful checks before leaving. Strong focus on new ideas plus global service keeps partnerships healthy for the long haul.
