| Fully Automatic SMT Printer Solution
The Solder Paste Stencil Spray Printing Machine from I.C.T delivers efficient, high-precision printing for SMT lines. It features a 7-second cycle, ±0.01mm repeat accuracy, and automatic controls for calibration, printing, and cleaning. This fully automatic SMT PCB printer supports various PCB sizes and types, including LED and automotive electronics. With Industry 4.0 compatibility and MES integration, it reduces waste, improves quality, and cuts costs. Ideal for modern factories, the SMT full automatic printer ensures stable performance using premium imported parts like Panasonic servomotors.
| Feature
The Solder Paste Stencil Spray Printing Machine features an arch bridge suspension type direct connection squeegee structure. Two high-precision stepping motors control the squeegee independently for accurate and stable pressure. Double side slide positioning rails ensure smooth operation before and after printing. This system supports glue printing and automatic pressure adjustment with real-time feedback, balancing squeegee pressure for perfect solder paste formation. It achieves high positional accuracy with repeated positioning at ±0.01mm and printing accuracy of 0.025mm. Programmable motors handle separation speed and distance among squeegee, stencil, and substrate, allowing multi-method separation. Ideal for consumer electronics and LED production, it reduces defects and improves efficiency in SMT lines.
This fully automatic SMT PCB printer uses a unique belt conveyor system to prevent PCB sticking effectively. The motor controls speed precisely, with accurate stop positions for reliable handling. PCB entry and exit directions are flexible, supporting left-right or right-left flows. Side clamps and vacuum nozzles clamp the PCB securely, ensuring smooth contact between PCB and stencil. The system handles various PCB sizes from 50x50mm to 900x600mm with warpage under 1%. Multi-functional positioning and programmable lifting platforms adjust to proper heights quickly. This setup boosts throughput, minimizes errors, and supports high-volume manufacturing in automotive and vehicle electronics.
The Solder Paste Stencil Spray Printing Machine offers dry, wet, and vacuum cleaning modes, plus manual options for flexibility. A unique spray system cleans evenly from top to bottom, controlled by software to save alcohol and paper. The special exhaust motor provides strong vacuum for effective residue removal. CCD and cleaning parts are separate for easy maintenance. It detects stencil holes with light compensation to judge cleanliness and triggers auto cleaning for better print quality. This system reduces material waste, ensures continuous operation, and maintains high standards in LED and general electronics industries.
| Specification
| Model | I.C.T-4034 | I.C.T5134 | I.C.T-5151 |
| Frame Size(mm) | 470*370 ~ 737*737 | 470*370 ~ 737*737 | 470*370 ~ 737*737 |
| PCB Size(mm) | 50*50 ~ 400*340 | 50*50 ~ 510*340 | 50*50 ~ 510*510 |
| Transport Direction | Left-Right; Right-Left; Left-Left; Right-Right | ||
| Support System | Magnetic Pin/Up-down table adjusted/support block | ||
| Clamping System | Side clamping(vacuum nozzle,Automation retractable Z pressure is option) | ||
| Printer Head | Two independent motorised printhead | ||
| Squeegee Type | Stainless steel(standard),plastic | ||
| Cleaning System | Dry, Wet, Vacuum | ||
| Inspection | 2D Inspection(Standard) | ||
| Power Supply | AC:220±10%,50/60HZ,3Kw | ||
| Control Method | PC Control | ||
| Dimension(mm) | 1220*1355*1500 | 1220*1355*1500 | 1220*1550*1500 |
| Model | I.C.T-6534 | I.C.T-6561 | I.C.T-9060 |
| Frame Size(mm) | 650*400 ~ 850*750 | 650*400 ~ 850*850 | 737*400 ~ 1100*900 |
| PCB Size(mm) | 50*50 ~ 650*340 | 80*50 ~ 650*610 | 80*50 ~ 900*600 |
| Dimension(mm) | 1330*1370*1500 | 1330*15450*1500 | 1580*1545*1500 |
* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.
| SMT Line Equipment List
Our High Quality PCBA Production Line features advanced equipment for efficient and precise PCB assembly. The fully automated SMT line includes a loader, an auto printer for accurate solder paste application, a pick-and-place machine for precise component placement, a reflow oven for reliable soldering, and an AOI system for thorough defect inspection. This High Quality PCBA Production Line ensures smooth operation, high reliability, and low-cost SMT assembly, meeting diverse industry requirements.
| Product Name | Purpose in SMT Line |
|---|---|
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
| Traceability Equipment | Records and tracks production data: Laser Marking Machine/Label Mounter/Inkjet Printer |
