| Advanced NG/OK SMT Unloader for Quality Lines
The I.C.T NG/OK SMT Unloader is the smart machine that takes boards from AOI or SPI and sorts them by pass/fail result. It stacks OK boards in one magazine and NG boards in another. Standard or full CE version—both have stronger structure, advanced sensors, and flexible software. The Translational NG/OK SMT Unloader reduces rework time, improves quality tracking, runs 24/7, and serves as a reliable Combination Loader For SMT Line. It connects easily to any SMT setup.
| Detailed Product Features
High-quality sensors read OK/NG signals clearly. Bright lights show status fast. The NG/OK SMT Unloader handles inspection results without mistakes and keeps sorting accurate.
Expandable Smart Control
The system supports Industry 4.0 features. Add IPC-CFX, Hermes, or other protocols anytime. Change settings quickly for new jobs. The NG/OK SMT Unloader links to factory systems and adjusts automatically.
Separate lowering units place OK and NG boards gently. The NG/OK SMT Unloader fills two magazines without damage or mix-up. Boards stay organized for next steps.
SMEMA interface is standard and ready. Optional advanced links available. The NG/OK SMT Unloader fits any line and keeps flow steady during changes.
SMEMA interface is standard and ready. Optional advanced links available. The NG/OK SMT Unloader fits any line and keeps flow steady during changes.
| Specification
| Model | DUL-M | DUL-L | DUL-LL | DUL-XL |
| Dimension(mm) | 1730*1530*1250 | 2065*1630*1250 | 2660*1760*1250 | 2660*1900*1250 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 | 50*50-530*460 |
| Rack Size(mm) | 355*320*563 | 460*400*563 | 535*460*563 | 535*530*563 |
| Control System | PLC | |||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | |||
| Weight | 340 Kg | 380 Kg | 420 Kg | 460 kg |
| SMT Line Equipment List
Our turnkey High-Quality SMT Production Line delivers fully automatic, high-speed, and ultra-reliable PCBA manufacturing. The proven setup starts with the Vacuum and Magazine Loader, moves to a precision automatic printer for perfect solder paste application, continues with high-speed pick-and-place machines for accurate component placement, passes through a stable reflow oven for strong solder joints, and finishes with advanced AOI inspection to catch any defect. Every machine communicates seamlessly, reducing labor and boosting first-pass yield. This complete solution meets automotive, medical, consumer, and LED industry standards while keeping operating costs low and uptime extremely high.
| Customer Success Story
In 2024, our engineers flew to Finland to install a fully automatic LED panel production line for a leading European lighting manufacturer. The line included the NG/OK SMT Unloader, 1.5m automatic printer, SM482PLUS placement machine, L8 reflow oven, vertical cooling buffer, linking conveyors, board splitter, and solder paste mixer. Our team finished installation, debugging, and operator training in just five days. The line reached full speed on the first production day with zero defects. The customer praised the accurate sorting of the NG/OK SMT Unloader and perfect machine communication. They passed the strict European audit easily and ordered another line soon.
| Professional Service and Training
I.C.T offers true one-stop support: on-site or remote installation, free operator and engineer training, 24/7 technical hotline, worldwide spare-parts stock, and preventive maintenance programs. Our experienced international team makes sure your Vacuum and Magazine Loader runs at peak performance for many years with almost zero unplanned stops.
| Customer Praise
“Engineers arrived quickly and solved our problem the same day.” “The NG/OK SMT Unloader is stable and very reliable.” “Packing was safe; machines arrived perfect after shipping.” “They respond fast and help us improve quality control.”
| I.C.T Quality Certificates
Every NG/OK SMT Unloader has CE, RoHS, ISO9001 certifications and multiple technical patents. Each machine goes through strict testing before shipment to guarantee top quality and safety for customers worldwide.
| Professional SMT Solution Provider
Founded in 2012, I.C.T now runs a modern 12,000 m² factory with nearly 90 employees and our own R&D center. We design, build, and test everything in-house under strict quality systems. Serving over 1,600 customers across 72 countries, we have grown fast by always putting customer success first. From a single Vacuum and Magazine Loader to complete turnkey lines, I.C.T is the long-term partner factories trust worldwide.
