| SMD Pick and Place Machine with Soldering
The SMD pick and place machine with soldering forms the steady center of modern SMT lines, mounting surface components with care and speed on PCBs of many kinds. JUKI models like the RS series offer balanced versatility for varied board sizes, while RX models bring exceptional output in limited floor space. Each machine places tiny chips, ICs, and larger parts with consistent accuracy, fitting smoothly between printing, reflow soldering, and inspection stages. The design emphasizes practical efficiency—quick changeovers, clear vision systems, and gentle handling that protects boards. I.C.T builds entire production systems around these machines, from initial layout through ongoing operation. Factories rely on them for LED strips, automotive electronics, consumer devices, and more. The result is reliable daily output that meets quality demands without unnecessary complexity.
| JUKI Pick and Place Machine Model Features
RS-1R / RS-1XL Series Features
The RS-1R and RS-1XL stand as dependable modular mounters built for everyday SMT needs. The RS-1R achieves 47,000 CPH optimum with placement accuracy of ±35µm (Cpk ≥1) and manages boards from 50×50 mm to 650×370 mm single clamping or up to 1,200×370 mm double. The RS-1XL extends capability to 650×560 mm boards, making it suitable for wider applications such as LED assemblies. Both use the Takumi head to handle components from 0201 metric to 74 mm square or 150×50 mm long shapes. They support up to 112 feeders for efficient changeovers. Compact dimensions allow easy line integration, while vision cameras and force control ensure precise, gentle placement. These models perform well in facilities that require flexibility across different production runs and steady performance over long hours.
RX-7R / RX-8 Series Features
The RX-7R and RX-8 focus on maximum productivity within small footprints. The RX-7R reaches 75,000 CPH with parallel heads, placing 03015 chips up to 25 mm square on boards as large as 510×450 mm single lane. The RX-8 advances to 100,000 CPH optimum using the P20 head, designed for dense small-component placement in high-volume settings. Both maintain a narrow 998 mm width, delivering the highest placement rates per square meter. They feature coaxial lighting for sharp vision, low-impact placement to protect boards, and real-time monitoring to reduce downtime. Dual-lane options and seamless integration with upstream and downstream equipment improve overall line flow. These machines suit demanding work on mobile devices, LED strips, automotive modules, and other products where space is limited and throughput matters most.
| Specification
| Parameter | RS-1R | RS-1XL | RX-7R | RX-8 |
|---|---|---|---|---|
| Placement Speed (Optimum CPH) | 47,000 | 42,000 | 75,000 | 100,000 |
| Maximum Board Size (mm) | 650 × 370 (single/double) | 650 × 560 | 510 × 450 (single lane) | 510 × 450 (approx.) |
| Minimum Board Size (mm) | 50 × 50 | 50 × 50 | 50 × 50 | 50 × 50 |
| Component Height (max mm) | 25 | 25 | 3-10.5 (head dependent) | 3 |
| Smallest Component | 0201 (metric) | 0201 (metric) | 03015 (metric) | 0201 (approx. 0.4×0.2mm) |
| Largest Component (mm) | 74 square / 150×50 | 74 square / 150×50 | 25 square | 5 square |
| Feeder Inputs (max) | 112 | 112 | 76 | 56 (approx.) |
| Placement Accuracy | ±35µm (Cpk ≥1) | ±35µm (Cpk ≥1) | ±40µm (approx.) | High precision (vision) |
| Machine Width (mm) | 1,500 (approx.) | 2,109 | 998 | 998 |
| Head Type | Takumi inline head | Takumi inline head | Parallel rotary heads (P16S) | P20 rotary head |
