| 8 Nozzle Pick and Place Machine Price
In the world of modern manufacturing, the SMD Chip Shooter Machine from Juki stands out with its blend of speed and precision. These modular systems mount surface devices onto boards with remarkable accuracy, handling everything from miniature chips to larger elements. The design allows easy expansion as needs grow, while intelligent cameras monitor each step closely. Programming flows intuitively, and the slim profile integrates seamlessly into busy floors. I.C.T guides the entire journey, from initial layout to daily optimization, ensuring steady performance for applications like automotive electronics and more. Quality emerges consistently, meeting demanding schedules.
| JUKI Pick and Place Machine Model Features
RS-1R / RS-1XL Series Features
Versatility defines the RS-1R and RS-1XL lineup. The dynamic Takumi head adapts in real time, managing diverse shapes and sizes effortlessly. Accuracy holds at ±35µm, while speeds reach 47,000 CPH on the RS-1R. Board handling extends to wider panels on the RS-1XL, up to 650×560mm, suiting large LED work. Up to 112 feeders enable swift transitions between jobs. Force control safeguards delicate substrates, and vision systems catch issues early. These models excel in mixed-production environments, combining smoothly with faster units for balanced, flexible lines that maintain high yield across varying demands.
RX-7R / RX-8 Series Features
At the heart of high-volume efficiency lie the RX-7R and RX-8. The innovative P20 head on the RX-8 drives placements to 100,000 CPH, leading in output per square meter. Parallel operations on the RX-7R deliver 75,000 CPH within a mere 998mm width. Both manage ultra-small 03015 chips flawlessly, aided by coaxial lighting for sharp imaging. Low-impact settings protect fragile components, and seamless data exchange reduces downtime. Smart monitoring tracks performance live. Ideal for dense, small-part assembly in mobile or driver boards, these machines transform space into superior productivity.
| Specification
| Parameter | RS-1R | RS-1XL | RX-7R | RX-8 |
|---|---|---|---|---|
| Placement Speed (Optimum CPH) | 47,000 | 42,000 | 75,000 | 100,000 |
| Maximum Board Size (mm) | 650 × 370 (single/double) | 650 × 560 | 510 × 450 (single lane) | 510 × 450 (approx.) |
| Minimum Board Size (mm) | 50 × 50 | 50 × 50 | 50 × 50 | 50 × 50 |
| Component Height (max mm) | 25 | 25 | 3-10.5 (head dependent) | 3 |
| Smallest Component | 0201 (metric) | 0201 (metric) | 03015 (metric) | 0201 (approx. 0.4×0.2mm) |
| Largest Component (mm) | 74 square / 150×50 | 74 square / 150×50 | 25 square | 5 square |
| Feeder Inputs (max) | 112 | 112 | 76 | 56 (approx.) |
| Placement Accuracy | ±35µm (Cpk ≥1) | ±35µm (Cpk ≥1) | ±40µm (approx.) | High precision (vision) |
| Machine Width (mm) | 1,500 (approx.) | 2,109 | 998 | 998 |
| Head Type | Takumi inline head | Takumi inline head | Parallel rotary heads (P16S) | P20 rotary head |
| SMT Line Equipment List
I.C.T crafts complete, high-quality PCBA lines built for lasting performance. The vacuum loader draws boards in without dust. Printer applies solder paste in perfect patterns. The SMD Chip Shooter Machine positions every component exactly. Multi-zone reflow ovens bond connections firmly. AOI systems detect flaws reliably. Conveyors and buffers maintain steady rhythm. Yields rise sharply while costs remain controlled. Nothing breaks the chain. Designed for rigorous automotive power modules and similar tasks, these lines produce boards ready for real-world demands. Full backing ensures confidence from start to ongoing operation.
| Product Name | Purpose in SMT Line |
|---|---|
| SMT Line | Ful-Auto SMT Production Line for Automotive, LED etc |
| PCB Loader | Automatically loads bare PCBs to the line. |
| Solder Paste Printer | Prints solder paste on PCB pads accurately. |
| Pick and Place Machine | Mounts components onto PCBs precisely. |
| Reflow Oven | Melts solder to form solid joints. |
| SMT AOI Machine | Inspects solder joints and placement defects. |
| SPI Machine | Checks solder paste height and quality. |
