I.C.T HNOUL-L | NG/OK Magazine SMT PCB Unloader

Share to:

I.C.T HNOUL-L | NG/OK Magazine SMT PCB Unloader

Name: I.C.T HNOUL-L | NG/OK Magazine SMT PCB Unloader
Brand: I.C.T
Rating: 5.0 (71 reviews)

Translational NG/OK SMT Magazine Unloader
Buy it with your trusted partner! I.C.T brings 26 years of experience in the SMT industry.
Highlights: On-site installation and training Available, 24/7 Customer Service. Highly Trained Experts.Accurate and economical. Vision guided DIY kit. Easy To Assemble. Open Source Software.

Model:
I.C.T HNOUL-L | NG/OK Magazine SMT PCB Unloader
Brand:
I.C.T

Availability:

Quantity:



Inquire Add to Basket

SMT Assembly Line Automatic Translational NG/OK SMT Unloader

Introduction

1.This device is used to receive board SMT circuit board production line operation, suitable for receive NG board and OK board after soldering.

2. PLC + touch screen Man-Machine Operating Key Surface.

3. Frequency Conversion Lifting Device, Smooth Movement.

4.5 kinds of PITCH choices can set the step of receiving pcba.

5. Simple Width Adjustment Design, Quick and Flexible Line Change.

6. Four-point positioning of magazine.

7. Translational Differentiation of NG and OK pcba.

8. Anti-jamming board design of the receiving pcba protection system.

9. Compatible SMEMA interface.

Translational NG/OK SMT Unloader

Modular design, optional assembly as per client's requipment.

Rugged steel design, improves equipment stability.

Top & Bottom pneumatic clamps to secure magazine rack.

Soft touch LED control panel or touch screen can be selected.

Body Material	European standard aluminum alloy		China
PLC	Panasonic		Japan
Touch Screen	Kunlun		China
Frequency Converter	Delta		Taiwan
Flexible Cable	Igus		Germany
Magnetic Switch	SMC		Japan
Cylinder	SMC		Japan
Bearing	NSK		Japan
Ball Screw	TBI		Taiwan
Electromagnetic Valve	AirTAC		Taiwan
Limit Switch	Omron		Japan
Sensor	Omron		Japan
Relay	Omron		Japan
Model	HNOUL-M	HNOUL-L	HNOUL-LL	HNOUL-XL
Dimension(mm)	178014501680	206516301680	266017601680	266019001680
PCB Size(mm)	8070-330250	8070-445330	8070-530390	8070-530460
Rack Size(mm)	355320563	460400563	535460563	535530563
Control System	PLC
Power Supply	1 PH AC 220V 50/60Hz (Option:110V to 380V)
Weight	360 Kg	380 Kg	420 Kg	460 Kg
