I.C.T-1200 | 1.2 Meter SMT Fully Automatic LED Stencil Printer

Share to:

I.C.T-1200 | 1.2 Meter SMT Fully Automatic LED Stencil Printer

Name: I.C.T-1200 | 1.2 Meter SMT Fully Automatic LED Stencil Printer
Brand: I.C.T
Rating: 5.0 (6 reviews)

Long Board 1.2 Meter LED Stencil Printer
I.C.T high precision automatic solder paste printer, correspond to industrial 4.0 and MES system.through a higher level of
automation,achieve zero defect.
Buy it with your trusted partner! I.C.T brings 26 years of experience in the SMT industry.

Model:
I.C.T-1200
Brand:
I.C.T

Availability:

Quantity:



Inquire Add to Basket

I.C.T-1200 | 1.2 Meter SMT Fully Automatic LED Stencil Printer

Introduce

I.C.T-1200/1500 LED is a high precision automatic solder paste printer, designed specifically for led and other large size products. Correspond to industrial 4.0 and MES system.through a higher level of automation, achieve zero defect.

Features:

1. High positional accuracy, repeated positioning accuracy ±0.015mm; printing accuracy 0.03mm;

2. Support glue printing, automatic control improves production efficiency, quality control and saves production cost;

3. Automatic PCB calibration, Squeegee pressure adjustable, Automatic printing, Automatic stencil cleaning;

4. Programmable motor controls separation speed and distance among squeegee, stencil and substrate, to realize multi-method separation;

5. Multi-functional PCB positioning system for convenient and accurate PCB positioning;

6. Programmable PCB lifting platform ensure the PCB to lift to a proper height;

7. Adopt company independently developed suspended print head with automatic pressure adjustment system. Support on-line real time pressure feedback and automatic squeegee pressure balancing. Accurate pressure control ensures perfect paste forming effect;

8. Applicable PCB types: LCD TV,LED,vehicle electronics.besides general electronics products;

9. SMEMA standard.

I.C.T Stencil Printer

I.C.T SMT Fully Automatic Stencil Printer-I.C.T-1200

SMT Fully Automatic LED Stencil Printer

1. Simple: Combined with advanced international concepts, based on the Oriental-designed operating system, easy to learn;

2. Expertise: Learn imported printer’s advanced design concepts, and the machine core components are using imported top brands; 3. High Quality: Import hardware configuration,low failure rate in production,more than a decade service life;

4. Safety: Based on the general rules of international design, close to imported printer rating, the highest security level;

5. Stable: Mature software, hardware and top production processes ensures stability of each equipment.

Model	I.C.T-1200	I.C.T-1500
Frame Size(mm)	737300~1500750	1100300~1800750
Frame Thickness	25~40mm
PCB Size(mm)	8050~1200350	8050~1500450
PCB Thickness	0.4~6mm(Program settings, automatic adjustment)
Transport Speed	Max 1500mm/s
Support System	Magnetic Pin/Up-down table adjusted/support block
Clamping System	Side clamping(vacuum nozzle, Automation retractable Z pressure is option)
Printer Head	Two independent motorized print head
Squeegee Speed	6~200mm/sec
Power Supply	AC 220±10%, 50/60HZ, 3Kw
Control Method	PC Control
Dimension(mm)	L2200W1200H1500	L2500W1200H1500
Weight	Approx:1500kg	Approx:1800kg

* The data is obtained under ambient temperature of 25℃ and humidity of 60%.

* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.

SMT LED Stencil Printer - Precision in LED PCB Assembly

Discover the SMT solution for precise LED PCB assembly with our state-of-the-art SMT LED Stencil Printer. Engineered to perfection, this specialized machine ensures accurate solder paste or adhesive application, guaranteeing flawless LED component placement. With cutting-edge technology and a commitment to excellence, our SMT LED Stencil Printer is the key to achieving the highest quality and efficiency in LED manufacturing. Elevate your LED production capabilities with us today and experience the future of electronics assembly.

FAQ:

1. What is an SMT LED Stencil Printer?

An SMT (Surface Mount Technology) LED Stencil Printer is a specialized machine designed for the precise application of solder paste or adhesive onto printed circuit boards (PCBs) used in LED lighting applications. This ensures the accurate placement of surface-mount components like LEDs on PCBs.

2. How does an SMT LED Stencil Printer work?

This machine utilizes advanced printing technology to accurately deposit solder paste or adhesive onto designated areas of a PCB. This precise process is vital for ensuring the quality and reliability of LED solder joints.

3. What are the key advantages of using an SMT LED Stencil Printer?

Precision: These machines provide precise solder paste deposition, reducing defects in LED assembly.
Efficiency: They automate the solder paste application process, saving time and improving consistency.
Versatility: SMT LED Stencil Printers can handle various PCB sizes and designs.
Cost Efficiency: Minimized solder paste wastage contributes to cost savings.

4. In which industries are SMT LED Stencil Printers commonly used?

SMT LED Stencil Printers are essential equipment in the LED lighting industry, serving applications such as LED bulb manufacturing, LED display panels, signage, and other LED-related products.

5. Can SMT LED Stencil Printers handle lead-free solder paste?

Yes, most SMT LED Stencil Printers are designed to work with lead-free solder paste, ensuring compliance with industry regulations and environmental standards.

6. What factors should I consider when choosing an SMT LED Stencil Printer?

When selecting an SMT LED Stencil Printer, consider factors such as print speed, accuracy, compatibility with your LED PCB designs, ease of maintenance, and the reputation of the manufacturer. Ensure the machine aligns with your specific LED production requirements.

7. How do I maintain an SMT LED Stencil Printer?

Routine maintenance includes cleaning the stencil, calibrating the machine, ensuring the correct solder paste consistency, and regular inspections for wear and tear. Refer to the machine's user manual for detailed maintenance instructions.
